Danfoss VLT AQUA Drive FC 202 Design Manual

8.12.2 E4h Terminal Dimensions
130BF668.10
6X 148 (5.8)
90 (3.5)
50 (2.0)
0 (0.0)
1
0 (0.0)
64 (2.5) 41 (1.6)
105 (4.1) 137 (5.4) 194 (7.6) 200 (7.9) 233 (9.2)
402 (15.8) 339 (13.4) 410 (16.1) 499 (19.6) 435 (17.1) 531 (20.9)
256 (10.1)
33 (1.3)
2
3
4
540 (21.2)
432 (17.0) 521 (20.5)
472 (18.6)
561 (22.1)
1 Mains terminals 3 Motor terminals
2 Brake or regen terminals 4 Ground terminals, M8 and M10 nuts
Figure 8.93 E4h Terminal Dimensions (Front View)
Exterior and Terminal Dimen...
VLT
®
AQUA Drive FC 202
146 Danfoss A/S © 01/2018 All rights reserved. MG22B222
