4.5 Kit Availability
Kit description
1)
D1h D2h D3h D4h D5h D6h D7h D8h E1h E2h E3h E4h
NEMA 3R outdoor weather shield O O – – – – – – – – – –
NEMA 3R protection for in-back/out-back cooling
kit
– – O O – – – – – – – –
USB in door O O O O O O O O S S – –
LCP, numerical O O O O O O O O O O O O
LCP, graphical
2)
O O O O O O O O O O O O
LCP cable, 3 m (9 ft) O O O O O O O O O O O O
Mounting kit for numerical LCP
(LCP, fasteners, gasket, and cable)
O O O O O O O O O O O O
Mounting kit for graphical LCP
(LCP, fasteners, gasket, and cable)
O O O O O O O O O O O O
Mounting kit for all LCPs
(fasteners, gasket, and cable)
O O O O O O O O O O O O
Mains shield – – – – – – – – O O – –
Grounding bar – – – – – – – – O O – –
Input plate option O O O O O O O O – – – –
Terminal blocks O O O O O O O O O O O O
Top entry for eldbus cables O O O O O O O O O O O O
Pedestal O O – – O O O O S S – –
In bottom/out-top cooling – – O O – – – – – – O O
In bottom/out-back cooling O O O O – – – – – – O O
In back/out-top cooling – – – – – – – – – – O O
In back/out-back cooling O O O O O O O O O O O O
Out top (only) cooling – – O O – – – – – – – –
Table 4.7 Available Kits for Enclosures D1h–D8h and E1h–E4h
1) S = standard, O = optional, and a dash indicates that the kit is unavailable for that enclosure. For kit descriptions and part numbers, see
chapter 13.2.6 Ordering Numbers for D1h–D8h Kits and chapter 13.2.7 Ordering Numbers for E1h–E4h Kits.
2) The graphical LCP comes standard with enclosures D1h–D8h and E1h–E4h. If more than 1 graphical LCP is required, the kit is available for
purchase.
