7.2 Electrical Data, 525–690 V
VLT
®
AQUA Drive FC 202
N75K N90K N110K
High/normal load HO NO HO NO HO NO
(High overload=150% current during 60 s, normal
overload=110% current during 60 s)
Typical shaft output at 525 V [kW] 45 55 55 75 75 90
Typical shaft output at 575 V [hp] 60 75 75 100 100 125
Typical shaft output at 690 V [kW] 55 75 75 90 90 110
Enclosure size D1h/D3h/D5h/D6h
Output current (3-phase)
Continuous (at 525 V) [A] 76 90 90 113 113 137
Intermittent (60 s overload) (at 525 V) [A] 114 99 135 124 170 151
Continuous (at 575/690 V) [A] 73 86 86 108 108 131
Intermittent (60 s overload)(at 575/690 V) [A] 110 95 129 119 162 144
Continuous kVA (at 525 V) [kVA] 69 82 82 103 103 125
Continuous kVA (at 575 V) [kVA] 73 86 86 108 108 131
Continuous kVA (at 690 V) [kVA] 87 103 103 129 129 157
Maximum input current
Continuous (at 525 V) [A] 74 87 87 109 109 132
Continuous (at 575/690 V) 70 83 83 104 104 126
Maximum number and size of cables per phase
- Mains, motor, brake, and load share [mm
2
(AWG)]
2x95 (2x3/0) 2x95 (2x3/0) 2x95 (2x3/0)
Maximum external mains fuses [A]
1)
160 315 315
Estimated power loss at 575 V [W]
2), 3)
1098 1162 1162 1428 1430 1740
Estimated power loss at 690 V [W]
2), 3)
1057 1204 1205 1477 1480 1798
Eciency
3)
0.98 0.98 0.98
Output frequency [Hz] 0–590 0–590 0–590
Heat sink overtemperature trip [°C (°F)]
110 (230) 110 (230) 110 (230)
Control card overtemperature trip [°C (°F)]
75 (167) 75 (167) 75 (167)
Table 7.5 Electrical Data for Enclosures D1h/D3h/D5h/D6h, Mains Supply 3x525–690 V AC
1) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
2) Typical power loss is at normal conditions and expected to be within
±
15% (tolerance relates to variety in voltage and cable conditions). These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-
eciency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for
slots A and B each add only 4 W.
3) Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 7.5 Ambient Conditions. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
Specications Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 45
7 7
