Danfoss VLT AQUA Drive FC 202 Design Manual

7 Specications
7.1 Electrical Data, 380–480 V
VLT
®
AQUA Drive FC 202
N110K N132 N160
High/normal load HO NO HO NO HO NO
(High overload=150% current during 60 s, normal
overload=110% current during 60 s)
Typical shaft output at 400 V [kW] 90 110 110 132 132 160
Typical shaft output at 460 V [hp] 125 150 150 200 200 250
Typical shaft output at 480 V [kW] 110 132 132 160 160 200
Enclosure size D1h/D3h/D5h/D6h
Output current (3-phase)
Continuous (at 400 V) [A] 177 212 212 260 260 315
Intermittent (60 s overload) (at 400 V)[A] 266 233 318 286 390 347
Continuous (at 460/480 V) [A] 160 190 190 240 240 302
Intermittent (60 s overload) (at 460/480 V) [kVA] 240 209 285 264 360 332
Continuous kVA (at 400 V) [kVA] 123 147 147 180 180 218
Continuous kVA (at 460 V) [kVA] 127 151 151 191 191 241
Continuous kVA (at 480 V) [kVA] 139 165 165 208 208 262
Maximum input current
Continuous (at 400 V) [A] 171 204 204 251 251 304
Continuous (at 460/480 V) [A] 154 183 183 231 231 291
Maximum number and size of cables per phase
- Mains, motor, brake, and load share [mm
2
(AWG)]
2x95 (2x3/0) 2x95 (2x3/0) 2x95 (2x3/0)
Maximum external mains fuses [A]
1)
315 350 400
Estimated power loss at 400 V [W]
2), 3)
2031 2559 2289 2954 2923 3770
Estimated power loss at 460 V [W]
2), 3)
1828 2261 2051 2724 2089 3628
Eciency
3)
0.98 0.98 0.98
Output frequency [Hz] 0–590 0–590 0–590
Heat sink overtemperature trip [°C (°F)]
110 (230) 110 (230) 110 (230)
Control card overtemperature trip [°C (°F)]
75 (167) 75 (167) 75 (167)
Table 7.1 Electrical Data for Enclosures D1h/D3h/D5h/D6h, Mains Supply 3x380–480 V AC
1) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
2) Typical power loss is at normal conditions and expected to be within
± 15% (tolerance relates to variety in voltage and cable conditions). These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-
eciency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for
slots A and B each add only 4 W.
3) Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 7.5 Ambient Conditions. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
Specications Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 41
7 7
