4.3 Overview of Enclosures, 380–500 V
Enclosure size D1h D2h D3h D4h D5h D6h D7h D8h
Power rating
1)
Output at 400 V (kW) 110–160 200–315 110–160 200–315 110–160 110–160 200–315 200–315
Output at 460 V (hp) 150–250 300–450 150–250 300–450 150–250 150–250 300–450 300–450
Protection rating
IP IP21/54 IP21/54 IP20 IP20 IP21/54 IP21/54 IP21/54 IP21/54
NEMA Type 1/12 Type 1/12 Type Chassis Type Chassis Type 1/12 Type 1/12 Type 1/12 Type 1/12
Hardware options
2)
Stainless steel back
channel
O O O O O O O O
Mains shielding O O – – O O O O
Space heater O O – – O O O O
RFI lter (Class A1) O O O O O O O O
Safe torque o S S S S S S S S
No LCP O O O O O O O O
Numerical LCP O O O O O O O O
Graphical LCP O O O O O O O O
Fuses O O O O O O O O
Heat sink access
3)
O O O O O O O O
Brake chopper – – O O O O O O
Regeneration terminals – – O O O O O O
Loadshare terminals – – O O – – – –
Fuses + loadshare – – O O – – – –
Disconnect – – – – – O – O
Circuit breakers – – – – – O – O
Contactors – – – – – O – O
24 V DC supply O O O O O O O O
Dimensions
Height, mm (in) 901 (35.5) 1107 (43.6) 909 (35.8)
1004 (39.5)
4)
1027 (40.4)
1027 (40.4)
4)
1324 (52.1) 1663 (65.5) 1978 (77.9) 2284 (89.9)
Width, mm (in) 325 (12.8) 325 (12.8) 250 (9.8) 375 (14.8) 325 (12.8) 325 (12.8) 420 (16.5) 420 (16.5)
Depth, mm (in) 379 (14.9) 379 (14.9) 375 (14.8) 375 (14.8) 381 (15.0) 381 (15.0) 386 (15.2) 406 (16.0)
Weight, kg (lb) 62 (137) 125 (276) 62 (137)
108 (238)
4)
125 (276)
179 (395)
4)
99 (218) 128 (282) 185 (408) 232 (512)
Table 4.3 D1h–D8h Drives, 380–480 V
1) All power ratings are taken at normal overload. Output is measured at 400 V (kW) and 460 V (hp).
2) S = standard, O = optional, and a dash indicates that the option is unavailable.
3) Heat sink access is not available with stainless steel back-channel option.
4) With optional load share and regen terminals.
Product Overview Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 13
