Enclosure size E1h E2h E3h E4h

Power rating

Output at 400 V (kW) 355–450 500–560 355–450 500–560

Output at 460 V (hp) 500–600 650–750 500–600 650–750

Protection rating

IP IP21/54 IP21/54

IP20

UL type Type 1/12 Type 1/12 Chassis Chassis

Hardware options

Stainless steel back channel O O O O

Mains shielding O O – –

Space heater O O – –

RFI lter (Class A1) O O O O

Safe torque o S S S S

No LCP O O O O

Graphical LCP O O O O

Fuses S S O O

Heat sink access O O O O

Brake chopper O O O O

Regen terminals O O O O

Load share terminals – – O O

Fuses + load share – – O O

Disconnect O O – –

Circuit breakers – – – –

Contactors – – – –

24 V DC supply (SMPS, 5 A) – – – –

Dimensions

Height, mm (in) 2043 (80.4) 2043 (80.4) 1578 (62.1) 1578 (62.1)

Width, mm (in) 602 (23.7) 698 (27.5) 506 (19.9) 604 (23.9)

Depth, mm (in) 513 (20.2) 513 (20.2) 482 (19.0) 482 (19.0)

Weight, kg (lb) 295 (650) 318 (700) 272 (600) 295 (650)

Table 4.4 E1h–E4h Drives, 380–480 V

1) All power ratings are taken at normal overload. Output is measured at 400 V (kW) and 460 V (hp).

2) If the enclosure is congured with load share or regen terminals, then the protection rating is IP00, otherwise the protection rating is IP20.

3) S = standard, O = optional, and a dash indicates that the option is unavailable.

Product Overview

VLT

AQUA Drive FC 202
