13 How to Order a Drive
13.1 Drive Congurator
X S A B CX X X X
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 302221 23 272524 26 28 29 31 373635343332 38 39
X D
Table 13.1 Type Code String
Product group
1–6
Model
7–10
Mains Voltage
11–12
Enclosure
13–15
Hardware conguration
16–23
RFI lter
16–17
Brake
18
Display (LCP)
19
PCB coating
20
Mains option
21
Adaptation A
22
Adaptation B
23
Software release
24–27
Software language
28
A options
29–30
B options
31–32
C0 options, MCO
33–34
C1 options
35
C option software
36–37
D options
38–39
Table 13.2 Type Code Example for Ordering a Drive
Congure the correct drive for the proper application by
using the internet-based drive congurator. The drive
congurator is found on the global internet site:
www.danfoss.com/drives. The congurator creates a type
code string and an 8-digit sales number, which can be
delivered to the local sales oce. It is also possible to
build a project list with several products and send it to a
Danfoss sales representative.
An example of a type code string is:
FC-202N355T5E20H4BGCXXXSXXXXA0BXCXXXXD0
The meaning of the characters in the string is
dened in
Table 13.4. In the example above, a PROFIBUS DP-V1 and a
24 V back-up option is built-in.
Drives are delivered automatically with a language package
relevant to the region from which they are ordered. Four
regional language packages cover the following languages:
Language package 1
English, German, French, Danish, Dutch, Spanish, Swedish,
Italian, and Finnish.
Language package 2
English, German, Chinese, Korean, Japanese, Thai,
Traditional Chinese, and Bahasa Indonesian.
Language package 3
English, German, Slovenian, Bulgarian, Serbian, Romanian,
Hungarian, Czech, and Russian.
Language package 4
English, German, Spanish, English US, Greek, Brazilian
Portuguese, Turkish, and Polish.
How to Order a Drive Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 207
