13.1.2 Ordering Type Code for Enclosures E1h–E4h
Description Position Possible option
Product group 1–6 FC-202
Model 7–10 N355: 355 kW (500 hp)
N400: 400 kW (550–600 hp)
N450: 450 kW (450–600 hp)
N500: 500 kW (500–650 hp)
N560: 560 kW (600–750hp)
N630: 630 kW (650 hp)
N710: 710 kW (750 hp)
N800: 800 kW (950 hp)
Mains voltage 11–12 T4: 380–480 V AC
T7: 525–690 V AC
Enclosure 13–15 E00: IP00/Chassis (only enclosures E3h/E4h with top regen/loadshare)
E20: IP20/Chassis
E21: IP21/Type 1
E54: IP54/Type 12
E2M: IP21/Type 1 + mains shield
E5M: IP54/Type 12 + mains shield
H21: IP21/Type 1 + space heater
H54: IP54/Type 12 + space heater
C20: IP20/Type 1 + stainless steel back channel
C21: IP21/Type 1 + stainless steel back channel
C54: IP54/Type 12 + stainless steel back channel
C2M: IP21/Type 1 + mains shield + stainless steel back channel
C5M: IP54/Type 12 + mains shield + stainless steel back channel
C2H: IP21/Type 1 + space heater + stainless steel back channel
C5H: IP54/Type 12 + space heater + stainless steel back channel
RFI lter 16–17 H2: RFI lter, class A2 (C3)
H4: RFI lter, class A1 (C2)
Brake 18 X: No brake chopper
B: Brake chopper mounted
T: Safe Torque O (STO)
U: Brake chopper + safe torque o
R: Regen terminals
S: Brake chopper + regen terminals (only enclosures E3h/E4h)
Display 19 X: No LCP
G: Graphical LCP (LCP-102)
J: No LCP + USB through the door
L: Graphical LCP + USB through the door
Coating PCB 20 C: Coated PCB
R: Coated PCB 3C3 + ruggedized
Mains option 21 X: No mains option
3: Mains disconnect + fuses
7: Fuses
A: Fuses + load share terminals (only enclosures E3h/E4h)
D: Load share terminals (only enclosures E3h/E4h)
Hardware, adaptation A 22 X: No option
Hardware, adaptation B 23 X: No option
Q: Heat sink access
Software release 24–28 SXXX: Latest release - standard software
S067: Integrated motion control software
How to Order a Drive Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 209
13 13
