Danfoss VLT AQUA Drive FC 202 Design Manual

13.1.1 Ordering Type Code for Enclosures D1h–D8h
Description Pos Possible choice
Product group 1-6 FC-202
Model 7–10 N55: 55 kW (75 hp)
N75: 75 kW (100 hp)
N90: 90 kW (125 hp)
N110: 110 kW (150 hp)
N132: 132 kW (200 hp)
N160: 160 kW (250 hp)
N200: 200 kW (300 hp)
N250: 250 kW (350 hp)
N315: 315 kW (400–450 hp)
Mains voltage 11-12 T4: 380–480 V AC
T7: 525–690 V AC
Enclosure 13-15 E20: IP20 (chassis - for installation in an external enclosure)
E2S: IP20/chassis - D3h Frame
E21: IP21 (NEMA 1)
E2D: IP21/Type-1 D1h Frame
E54: IP54 (NEMA 12)
E5D: IP54/Type-12 D1h Frame
E2M: IP21 (NEMA 1) with mains shield
E5M: IP54 (NEMA 12) with mains shield
C20: IP20 (chassis) + stainless steel back channel
C2S: IP20/chassis with stainless steel back channel - D3h Frame
H21: IP21 (NEMA 1) + heater
H54: IP54 (NEMA 12) + heater
RFI lter 16-17 H2: RFI lter, class A2 (standard)
H4: RFI lter class A1
1)
Brake 18 X: No brake IGBT
B: Brake IGBT mounted
R: Regeneration terminals
S: Brake + regeneration (IP20 only)
Display 19 G: Graphical Local Control Panel LCP
N: Numerical Local Control Panel (LCP)
X: No Local Control Panel
PCB coating 20 C: Coated PCB
R: Coated PCB + ruggedized
Mains option 21 X: No mains option
3: Mains disconnect and fuse
4: Mains contactor + fuses
7: Fuse
A: Fuse and load sharing (IP20 only)
D: Load share terminals (IP20 only)
E: Mains disconnect + contactor + fuses
J: Circuit breaker + fuses
Adaptation 22 X: Standard cable entries
Adaptation 23 X: No adaptation
Q: Heat sink access panel
Software release 24-27 Actual software
Software language 28 X: Standard language pack
Table 13.3 Ordering Type Code for Enclosures D1h–D8h
1)
Available for all D-frames.
How to Order a Drive
VLT
®
AQUA Drive FC 202
