4.4 Overview of Enclosures, 525–690 V
Enclosure size D1h D2h D3h D4h D5h D6h D7h D8h
Power rating
1)
Output at 690 V (kW) 75–160 200–400 75–160 200–400 75–160 75–160 200–400 200–400
Output at 575 V (hp) 75–200 250–400 75–200 250–400 75–200 75–200 250–400 250–400
Protection rating
IP IP21/54 IP21/54 IP20 IP20 IP21/54 IP21/54 IP21/54 IP21/54
NEMA Type 1/12 Type 1/12 Type Chassis Type Chassis Type 1/12 Type 1/12 Type 1/12 Type 1/12
Hardware options
2)
Stainless steel back-
channel
– – O O – – – –
Mains shielding O O O O O O O O
Space heater O O O O O O O O
Safe torque o S S S S S S S S
No LCP O O O O O O O O
Numerical LCP O O O O O O O O
Graphical LCP O O O O O O O O
Fuses O O O O O O O O
Heat sink access
3)
O O O O O O O O
Brake chopper – – O O O O O XO
Regeneration terminals – – O O – – – –
Loadshare terminals – – O O O O O O
Fuses + loadshare – – O O – – – –
Disconnect – – – – O O O O
Circuit breakers – – – – – O – O
Contactors – – – – – O – O
24 V DC supply O O O O O O O O
Dimensions
Height, mm (in) 901 (35.5) 1107 (43.6) 909 (35.8)
1004 (39.5)
4)
1027 (40.4)
1027 (40.4)
4)
1324 (52.1) 1663 (65.5) 1978 (77.9) 2284 (89.9)
Width, mm (in) 325 (12.8) 325 (12.8) 250 (9.8) 375 (14.8) 325 (12.8) 325 (12.8) 420 (16.5) 420 (16.5)
Depth, mm (in) 379 (14.9) 379 (14.9) 375 (14.8) 375 (14.8) 381 (15.0) 381 (15.0) 386 (15.2) 406 (16.0)
Weight, kg (lb) 62 (137) 125 (276) 62 (137)
108 (238)
4)
125 (276)
179 (395)
4)
99 (218) 128 (282) 185 (408) 232 (512)
Table 4.5 D1h–D8h Drives, 525–690 V
1) All power ratings are taken at normal overload. Output is measured at 690 V (kW) and 575 V (hp).
2) S = standard, O = optional, and a dash indicates that the option is unavailable.
3) Heat sink access is not available with stainless steel back-channel option.
4) With optional load share and regen terminals.
Product Overview Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 15
4 4
