Speed accuracy (open loop) 30–4000 RPM: Maximum error of ±8 RPM
All control characteristics are based on a 4-pole asynchronous motor.
Control card performance
Scan interval 5 M/S
Control card, USB serial communication
USB standard 1.1 (full speed)
USB plug USB type B device plug
NOTICE!
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB connection is not galvanically isolated from ground. Use only isolated laptop/PC as connection to the USB
connector on the drive or an isolated USB cable/converter.
7.8 Enclosure Weights
Enclosure 380–480/500 V 525–690 V
D1h 62 (137) 62 (137)
D2h 125 (276) 125 (276)
D3h 62 (137)
108 (238)
1)
62 (137)
108 (238)
1)
D4h 125 (276)
179 (395)
1)
125 (276)
179 (395)
1)
D5h 99 (218) 99 (218)
D6h 128 (282) 128 (282)
D7h 185 (408) 185 (408)
D8h 232 (512) 232 (512)
Table 7.12 Enclosure D1h–D8h Weights, kg (lb)
1) With optional load share and regen terminals.
Enclosure 380–480/500 V 525–690 V
E1h 295 (650) 295 (650)
E2h 318 (700) 318 (700)
E3h 272 (600) 272 (600)
E4h 295 (650) 295 (650)
Table 7.13 Enclosure E1h–E4h Weights, kg (lb)
Specications
VLT
®
AQUA Drive FC 202
56 Danfoss A/S © 01/2018 All rights reserved. MG22B222
