Enclosure size E1h E2h E3h E4h

Power rating

Output at 690 V (kW) 450–630 710–800 450–630 710–800

Output at 575 V (hp) 450–650 750–950 450–650 750–950

Protection rating

IP IP21/54 IP21/54

IP20

UL type Type 1/12 Type 1/12 Chassis Chassis

Hardware options

Stainless steel back channel O O O O

Mains shielding O O – –

Space heater O O – –

RFI lter (Class A1) – – – –

Safe torque o S S S S

No LCP O O O O

Graphical LCP O O O O

Fuses S S O O

Heat sink access O O O O

Brake chopper O O O O

Regen terminals O O O O

Load share terminals – – O O

Fuses + load share – – O O

Disconnect O O – –

Circuit breakers – – – –

Contactors – – – –

24 V DC supply (SMPS, 5 A) – – – –

Dimensions

Height, mm (in) 2043 (80.4) 2043 (80.4) 1578 (62.1) 1578 (62.1)

Width, mm (in) 602 (23.7) 698 (27.5) 506 (19.9) 604 (23.9)

Depth, mm (in) 513 (20.2) 513 (20.2) 482 (19.0) 482 (19.0)

Weight, kg (lb) 295 (650) 318 (700) 272 (600) 295 (650)

Table 4.6 E1h–E4h Drives, 525–690 V

1) All power ratings are taken at normal overload. Output is measured at 690 V (kW) and 575 V (hp).

2) If the enclosure is congured with load share or regen terminals, then the protection rating is IP00, otherwise the protection rating is IP20.

3) S = standard, O = optional, and a dash indicates that the option is unavailable.

Product Overview

VLT

AQUA Drive FC 202
