In-back/out-back (Non-Rittal
enclosures), D3h
Allows the cooling air to be directed in and out through the back of
the drive. Does not include plates for mounting in the enclosure. This
kit is used only for enclosure D3h.
176F3519 176F3520
In-back/out-back (Non-Rittal
enclosures), D4h
Allows the cooling air to be directed in and out through the back of
the drive. Does not include plates for mounting in the enclosure. This
kit is used only for enclosure D4h.
176F3524 176F3525
In bottom/out back, D1h/D3h Allows the cooling air to be directed in through the bottom and out
through the back of the drive. This kit is used only for enclosures
D1h/D3h.
176F3522 176F3523
In bottom/out back, D2h/D4h Allows the cooling air to be directed in through the bottom and out
through the back of the drive. This kit is used only for enclosures
D2h/D4h.
176F3527 176F3528
In back/out back, D1h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure D1h.
176F3648 176F3656
In back/out back, D2h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure D2h.
176F3649 176F3657
In back/out back, D3h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure D3h.
176F3625 176F3654
In back/out back, D4h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure D4h.
176F3626 176F3655
In back/out back, D5h/D6h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosures D5h/D6h.
176F3530
In back/out back, D7h/D8h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosures D7h/D8h.
176F3531
LCP
LCP 101 Numerical local control panel (NLCP). 130B1124
LCP 102 Graphical Local control panel (GLCP). 130B1107
LCP cable Separate LCP cable, 3 m (9 ft). 175Z0929
LCP kit, IP21 Panel mounting kit including graphical LCP, fasteners, 3 m (9 ft) cable
and gasket.
130B1113
LCP kit, IP21 Panel mounting kit including numerical LCP, fasteners and gasket. 130B1114
LCP kit, IP21 Panel mounting kit for all LCPs including fasteners, 3 m (9 ft) cable
and gasket.
130B1117
External options
EtherNet/IP Ethernet master. 175N2584
Table 13.11 Kits Available for Enclosures D1h–D8h
13.2.7 Ordering Numbers for E1h–E4h Kits
Type Description Ordering number
Miscellaneous hardware
PROFIBUS top entry, E1h–E4h Top entry for enclosure protection rating IP54. 176F1742
USB in the door, E1h–E4h USB extension cord kit to allow access to the drive controls via laptop
computer without opening the drive.
130B1156
Ground bar More grounding points for E1h and E2h drives. 176F6609
Mains shield, E1h Shielding (cover) mounted in front of the power terminals to protect
from accidental contact.
176F6619
Mains shield, E2h Shielding (cover) mounted in front of the power terminals to protect
from accidental contact.
176F6620
Terminal blocks Screw terminal blocks for replacing spring loaded terminals.
(1 pc 10 pin 1 pc 6 pin and 1 pc 3-pin connectors)
130B1116
Back-channel cooling kits Standard Stainless steel
How to Order a Drive Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 213
