Danfoss VLT AQUA Drive FC 202 Design Manual

In bottom/out top, E3h Allows the cooling air to be directed in through the bottom and out
through the top of the drive. This kit is used only for enclosure E3h
with the 600 mm (21.6 in) base plate.
176F6606 –
In bottom/out top, E3h Allows the cooling air to be directed in through the bottom and out
through the top of the drive. This kit used only for enclosure E3h with
800 mm (31.5 in) base plate.
176F6607 –
In bottom/out top, E4h Allows the cooling air to be directed in through the bottom and out
through the top of the drive. This kit is used only for enclosure E4h
with the 800 mm (31.5 in) base plate.
176F6608 –
In back/out back, E1h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure E1h.
176F6617 –
In back/out back, E2h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure E2h.
176F6618 –
In back/out back, E3h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure E3h.
176F6610 –
In back/out back, E4h Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure E4h.
176F6611 –
In bottom/out back, E3h Allows the cooling air to be directed in through the bottom and out
through the back of the drive. This kit is used only for enclosure E3h
with the 600 mm (21.6 in) base plate.
176F6612 –
In bottom/out back, E3h Allows the cooling air to be directed in through the bottom and out
through the back of the drive. This kit used only for enclosure E3h
with the 800 mm (31.5 in) base plate.
176F6613 –
In bottom/out back, E4h Allows the cooling air to be directed in through the bottom and out
through the back of the drive. This kit is used only for enclosure E4h
with 800 mm (31.5 in) base plate.
176F6614 –
In back/out top, E3h Allows the cooling air to be directed in through the back and out
through the top of the drive. This kit is used only for enclosure E3h.
176F6615 –
In back/out top, E4h Allows the cooling air to be directed in through the back and out
through the top of the drive. This kit is used only for enclosure E4h.
176F6616 –
LCP
LCP 101 Numerical local control panel (NLCP). 130B1124
LCP 102 Graphical Local control panel (GLCP). 130B1107
LCP cable Separate LCP cable, 3 m (9 ft). 175Z0929
LCP kit, IP21 Panel mounting kit including graphical LCP, fasteners, 3 m (9 ft) cable
and gasket.
130B1113
LCP kit, IP21 Panel mounting kit including numerical LCP, fasteners and gasket. 130B1114
LCP kit, IP21 Panel mounting kit for all LCPs including fasteners, 3 m (9 ft) cable
and gasket.
130B1117
External options
EtherNet/IP Ethernet master. 175N2584
Table 13.12 Kits Available for Enclosures E1h–E4h
How to Order a Drive
VLT
®
AQUA Drive FC 202
214 Danfoss A/S © 01/2018 All rights reserved. MG22B222
1313
