Danfoss VLT AQUA Drive FC 202 Design Manual

NEMA 3R outdoor weather
shield, D2h
Shield designed to protect drive openings from direct sun, snow, and
falling debris. Drives using this shield must be ordered from the
factory as NEMA 3R ready, which is found in the type code as E5S
enclosure option.
176F6303
NEMA 3R for in-back/out-back
cooling kit within a welded
enclosure, D3h
Provides an ingress protection rating of NEMA 3R or NEMA 4. These
enclosures are intended for outdoor use to provide protection against
inclement weather.
176F3521
NEMA 3R for in-back/out-back
cooling kit within a Rittal
enclosure, D3h
Provides an ingress protection rating of NEMA 3R or NEMA 4. These
enclosures are intended for outdoor use to provide protection against
inclement weather.
176F3633
NEMA 3R for in-back/out-back
cooling kit within a welded
enclosure, D4h
Provides an ingress protection rating of NEMA 3R or NEMA 4. These
enclosures are intended for outdoor use to provide protection against
inclement weather.
176F3526
NEMA 3R for in-back/out-back
cooling kit within a Rittal
enclosure, D3h
Provides an ingress protection rating of NEMA 3R or NEMA 4. These
enclosures are intended for outdoor use to provide protection against
inclement weather.
176F3634
Adaptor plate, D1h/D3h Plate used to replace an enclosure D1/D3 with the D1h/D3h using the
same mounting conguration.
176F3409
Adaptor plate, D2h/D4h Plate used to replace an enclosure D2/D4 with the D2h/D4h using the
same mounting conguration.
176F3410
Back-channel duct kit, D3h Duct kit that converts enclosure to either in-bottom/out-top venting
or top only venting. Enclosure size: 1800 mm (70.9 in).
176F3627
Back-channel duct kit, D3h Duct kit that converts enclosure to either in-bottom/out-top venting
or top only venting. Enclosure size: 2000 mm (78.7 in).
176F3629
Back-channel duct kit, D4h Duct kit that converts enclosure to either in-bottom/out-top venting
or top only venting. Enclosure size: 1800 mm (70.9 in).
176F3628
Back-channel duct kit, D4h Duct kit that converts enclosure to either in-bottom/out-top venting
or top only venting. Enclosure size: 2000 mm (78.7 in).
176F3630
Pedestal, D1h Provides a 400 mm (15.7 in) pedestal that allows the drive to be oor
mounted. The front of the pedestal has openings for input air to cool
the power components.
176F3631
Pedestal, D2h Provides a 400 mm (15.7 in) pedestal that allows the drive to be oor
mounted. The front of the pedestal has openings for input air to cool
the power components.
176F3632
Pedestal, D5h/D6h Provides a 200 mm (7.9 in) pedestal that allows the drive to be oor
mounted. The front of the pedestal has openings for input air to cool
the power components.
176F3452
Pedestal, D7h/D8h Provides a 200 mm (7.9 in) pedestal that allows the drive to be oor
mounted. The front of the pedestal has openings for input air to cool
the power components.
176F3539
Top entry of eldbus cables,
D1h–D8h
Allows for the installation of eldbus cables through the top of the
drive. The kit is IP20/chassis when installed, but a dierent mating
connector can be used to increase the protection rating.
176F3594
USB in the door, D1h–D8h
(IP20/chassis)
USB extension cord kit to allow access to the drive controls via laptop
computer without opening the drive.
Contact factory
USB in the door, D1h–D8h
(IP21/Type 1 and IP54/Type 12)
USB extension cord kit to allow access to the drive controls via laptop
computer without opening the drive.
Contact factory
Input plate option, D1h–D8h Allows fuses, disconnect/fuses, RFI, FRI/fuses, and RFI/disconnect/fuses
options to be added.
Contact factory
Terminal blocks Screw terminal blocks for replacing spring loaded terminals.
(1 pc 10 pin 1 pc 6 pin and 1 pc 3-pin connectors)
130B1116
Back-channel cooling kits Standard Stainless steel
How to Order a Drive
VLT
®
AQUA Drive FC 202
212 Danfoss A/S © 01/2018 All rights reserved. MG22B222
