8-42 PCD Write Conguration
Range: Function:
[413] Motor Speed
High Limit
[RPM]
[414] Motor Speed
High Limit
[Hz]
[416] Torque Limit
Motor Mode
[417] Torque Limit
Generator
Mode
[553] Term. 29 High
Ref./Feedb.
Value
[558] Term. 33 High
Ref./Feedb.
Value
[590] Digital & Relay
Bus Control
[593] Pulse Out #27
Bus Control
[595] Pulse Out #29
Bus Control
[597] Pulse Out
#X30/6 Bus
Control
[615] Terminal 53
High Ref./
Feedb. Value
[625] Terminal 54
High Ref./
Feedb. Value
[653] Terminal 42
Output Bus
Control
[663] Terminal
X30/8 Output
Bus Control
[673] Terminal
X45/1 Bus
Control
[683] Terminal
X45/3 Bus
Control
[890] Bus Jog 1
Speed
[891] Bus Jog 2
Speed
[894] Bus Feedback
1
[895] Bus Feedback
2
[896] Bus Feedback
3
8-42 PCD Write Conguration
Range: Function:
[1680] Fieldbus CTW
1
[1682] Fieldbus REF 1
[1685] FC Port CTW 1
[1686] FC Port REF 1
[2013] Minimum
Reference/
Feedb.
[2014] Maximum
Reference/
Feedb.
[2021] Setpoint 1
[2022] Setpoint 2
[2023] Setpoint 3
[2643] Terminal
X42/7 Bus
Control
[2653] Terminal
X42/9 Bus
Control
[2663] Terminal
X42/11 Bus
Control
[3401] PCD 1 Write
to MCO
[3402] PCD 2 Write
to MCO
[3403] PCD 3 Write
to MCO
[3404] PCD 4 Write
to MCO
[3405] PCD 5 Write
to MCO
[3406] PCD 6 Write
to MCO
[3407] PCD 7 Write
to MCO
[3408] PCD 8 Write
to MCO
[3409] PCD 9 Write
to MCO
[3410] PCD 10 Write
to MCO
[3644] Terminal
X49/7 Bus
Control
[3654] Terminal
X49/9 Bus
Control
[3664] Terminal
X49/11 Bus
Control
Parameter Descriptions
VLT
®
HVAC Drive FC 102
