8-43 PCD Read Conguration
Range: Function:
[0] None
[15] Readout:
actual setup
[894] Bus Feedback
1
[895] Bus Feedback
2
[896] Bus Feedback
3
[1397] Alert Alarm
Word
[1398] Alert Warning
Word
[1399] Alert Status
Word
[1500] Operating
hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference
[Unit]
[1602] Reference [%]
[1603] Status Word
[1605] Main Actual
Value [%]
[1609] Custom
Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1619] Thermistor
Sensor
Temperature
[1622] Torque [%]
[1623] Motor Shaft
Power [kW]
[1624] Calibrated
Stator
Resistance
[1626] Power Filtered
[kW]
[1627] Power Filtered
[hp]
[1630] DC Link
Voltage
8-43 PCD Read Conguration
Range: Function:
[1632] Brake
Energy /s
[1633] Brake Energy
Average
[1634] Heatsink
Temp.
[1635] Inverter
Thermal
[1638] SL Controller
State
[1639] Control Card
Temp.
[1642] Service Log
Counter
[1645] Motor Phase U
Current
[1646] Motor Phase V
Current
[1647] Motor Phase
W Current
[1650] External
Reference
[1652] Feedback[Unit]
[1653] Digi Pot
Reference
[1654] Feedback 1
[Unit]
[1655] Feedback 2
[Unit]
[1656] Feedback 3
[Unit]
[1660] Digital Input
[1661] Terminal 53
Switch Setting
[1662] Analog Input
53
[1663] Terminal 54
Switch Setting
[1664] Analog Input
54
[1665] Analog Output
42 [mA]
[1666] Digital Output
[bin]
[1667] Pulse Input
#29 [Hz]
[1668] Pulse Input
#33 [Hz]
[1669] Pulse Output
#27 [Hz]
[1670] Pulse Output
#29 [Hz]
Parameter Descriptions Programming Guide
