13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[37] Digital input
DI32
[38] Digital input
DI33
[39] Start
command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset
Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[76] Digital Input
x30 2
[77] Digital Input
x30 3
[78] Digital Input
x30 4
13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive
Mode
[91] ECB Bypass
Mode
[92] ECB Test Mode
[93] RS Flipop 6
[94] RS Flipop 0
[95] RS Flipop 1
[96] RS Flipop 2
[97] RS Flipop 3
[98] RS Flipop 4
[99] RS Flipop 5
[100] Fire Mode See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
[101] RS Flipop 7
[103] Relay 1
[104] Relay 2
[109] Relay 7
[110] Relay 8
[111] Relay 9
[140] ATEX ETR cur.
warning
[141] ATEX ETR cur.
alarm
[142] ATEX ETR freq.
warning
[143] ATEX ETR freq.
alarm
[144] Pressure 1
Low
[145] Pressure 2
Low
[146] Pressure 3
Low
[147] Pressure 4
Low
[148] Pressure 1
High
[149] Pressure 2
High
[150] Pressure 3
High
[151] Pressure 4
High
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 141
3 3
