Danfoss vlt FC 102 Programming Guide

3.13.7 13-5* States
13-51 SL Controller Event
Array [20]
Option: Function:
Select the boolean input (true or
false) to dene the smart logic
controller event.
See parameter 13-02 Stop Event for
further descriptions of options and
their functions.
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current
range
[8] Below I low
[9] Above I high
[10] Out of speed
range
[11] Below speed
low
[12] Above speed
high
[13] Out of feedb.
range
[14] Below feedb.
low
[15] Above feedb.
high
[16] Thermal
warning
[17] Mains out of
range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip
lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
13-51 SL Controller Event
Array [20]
Option: Function:
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[37] Digital input
DI32
[38] Digital input
DI33
[39] Start
command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset
Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[76] Digital Input
x30 2
[77] Digital Input
x30 3
[78] Digital Input
x30 4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive
Mode
[91] ECB Bypass
Mode
[92] ECB Test Mode
[93] RS Flipop 6
[94] RS Flipop 0 See parameter 13-15 RS-FF Operand
S, parameter 13-16 RS-FF Operand R.
Parameter Descriptions
VLT
®
HVAC Drive FC 102
142 Danfoss A/S © 10/2019 All rights reserved. M0010001
33
