13-51 SL Controller Event
Array [20]
Option: Function:
[95] RS Flipop 1 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[96] RS Flipop 2 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[97] RS Flipop 3 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[98] RS Flipop 4 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[99] RS Flipop 5 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[100] Fire Mode See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[101] RS Flipop 7 See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
[103] Relay 1
[104] Relay 2
[109] Relay 7
[110] Relay 8
[111] Relay 9
[140] ATEX ETR cur.
warning
[141] ATEX ETR cur.
alarm
[142] ATEX ETR freq.
warning
[143] ATEX ETR freq.
alarm
[144] Pressure 1
Low
[145] Pressure 2
Low
[146] Pressure 3
Low
[147] Pressure 4
Low
[148] Pressure 1
High
[149] Pressure 2
High
[150] Pressure 3
High
[151] Pressure 4
High
13-52 SL Controller Action
Array [20]
Option: Function:
Select the action corresponding to
the SLC event. Actions are executed
when the corresponding event
(dened in parameter 13-51 SL
Controller Event) is evaluated as
true. The following actions are
available for selection:
[0] Disabled
[1] No action
[2] Select set-up 1 Changes the active set-up
(parameter 0-10 Active Set-up) to 1.
[3] Select set-up 2 Changes the active set-up
(parameter 0-10 Active Set-up) to 2.
[4] Select set-up 3 Changes the active set-up
(parameter 0-10 Active Set-up) to 3.
[5] Select set-up 4 Changes the active set-up
(parameter 0-10 Active Set-up) to 4.
If the set-up is changed, it merges
with other set-up commands
coming from either the digital
inputs or via a eldbus.
[10] Select preset
ref 0
Selects preset reference 0.
[11] Select preset
ref 1
Selects preset reference 1.
[12] Select preset
ref 2
Selects preset reference 2.
[13] Select preset
ref 3
Selects preset reference 3.
[14] Select preset
ref 4
Selects preset reference 4.
[15] Select preset
ref 5
Selects preset reference 5.
[16] Select preset
ref 6
Selects preset reference 6.
[17] Select preset
ref 7
Selects preset reference 7. If the
active preset reference is changed,
it merges with other preset
reference commands coming from
either the digital inputs or via a
eldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
[22] Run Issues a start command to the
frequency converter.
[23] Run reverse Issues a start reverse command to
the frequency converter.
[24] Stop Issues a stop command to the
frequency converter.
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 143
3 3
