35-17 Term. X48/4 High Temp. Limit
Range: Function:
operation of the temperature
sensor at terminal X48/4.
3.28.2 35-2* Temp. Input X48/7 (MCB 114)
35-24 Term. X48/7 Filter Time Constant
Range: Function:
0.005 s* [0.005 - 10 s] Enter the lter time constant. This is
a rst-order digital low-pass lter
time constant for suppressing
electrical noise in terminal X48/7. A
high time constant value improves
dampening but also increases the
time delay through the lter.
35-25 Term. X48/7 Temp. Monitor
This parameter facilitates the possibility of enabling or disabling
the temperature monitor for terminal X48/7. Set the temperature
limits in parameter parameter 35-26 Term. X48/7 Low Temp. Limit
and parameter 35-27 Term. X48/7 High Temp. Limit.
Option: Function:
[0] * Disabled
[1] Enabled
35-26 Term. X48/7 Low Temp. Limit
Range: Function:
Size
related*
[ -50 - par.
35-27 ]
Enter the minimum temperature
reading that is expected for normal
operation of the temperature
sensor at terminal X48/7.
35-27 Term. X48/7 High Temp. Limit
Range: Function:
Size
related*
[ par. 35-26 -
204 ]
Enter the maximum temperature
reading that is expected for normal
operation of the temperature
sensor at terminal X48/7.
3.28.3 35-3* Temp. Input X48/10 (MCB 114)
35-34 Term. X48/10 Filter Time Constant
Range: Function:
0.005 s* [0.005 - 10 s] Enter the lter time constant. This is
a rst-order digital low-pass lter
time constant for suppressing
electrical noise in terminal X48/10.
A high time constant value
improves dampening but also
increases the time delay through
the lter.
35-35 Term. X48/10 Temp. Monitor
This parameter facilitates the possibility of enabling or disabling
the temperature monitor for terminal X48/10. Set the
temperature limits in parameter 35-36 Term. X48/10 Low Temp.
Limit / parameter 35-37 Term. X48/10 High Temp. Limit.
Option: Function:
[0] * Disabled
[1] Enabled
35-36 Term. X48/10 Low Temp. Limit
Range: Function:
Size
related*
[ -50 - par.
35-37 ]
Enter the minimum temperature
reading that is expected for normal
operation of the temperature
sensor at terminal X48/10.
35-37 Term. X48/10 High Temp. Limit
Range: Function:
Size
related*
[ par. 35-36 -
204 ]
Enter the maximum temperature
reading that is expected for normal
operation of the temperature
sensor at terminal X48/10.
3.28.4 35-4* Analog Input X48/2 (MCB 114)
35-42 Term. X48/2 Low Current
Range: Function:
4 mA* [ 0 - par.
35-43 mA]
Enter the current (mA) that
corresponds to the low reference
value, set in parameter 35-44 Term.
X48/2 Low Ref./Feedb. Value. The
value must be more than 2 mA to
activate the live zero timeout
function in parameter 6-01 Live Zero
Timeout Function.
35-43 Term. X48/2 High Current
Range: Function:
20 mA* [ par. 35-42 -
20 mA]
Enter the current (mA) that
corresponds to the high reference
value set in parameter 35-45 Term.
X48/2 High Ref./Feedb. Value.
35-44 Term. X48/2 Low Ref./Feedb. Value
Range: Function:
0* [-999999.999
- 999999.999 ]
35-45 Term. X48/2 High Ref./Feedb. Value
Range: Function:
100* [-999999.999
- 999999.999 ]
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 261
3 3
