Danfoss vlt FC 102 Programming Guide

36-43 Terminal X49/7 Max. Scale
Range: Function:
parameter 6-52 Terminal 42 Output
Max Scale
Example
Parameter 36-03 Terminal X49/7
Mode=[0] Voltage 0-10 V
Parameter 36-40 Terminal X49/7
Analogue Output=[100] Output
frequency
Parameter 4-19 Max Output
Frequency=200 Hz
Example case 1: 5 V maximum
output is required when the output
frequency is 200 Hz.
Parameter 36-43 Terminal X49/7 Max.
Scale = (10 V/5 V) x 100% = 200%.
Example case 2: 10 V maximum
output is required when the output
frequency is 150 Hz (75% of the
maximum output frequency).
Parameter 36-43 Terminal X49/7 Max.
Scale = 75%.
36-44 Terminal X49/7 Bus Control
Range: Function:
0 %* [0 - 100 %] This parameter contains the output
level of terminal X49/7 if the
terminal is controlled by a eldbus.
36-45 Terminal X49/7 Timeout Preset
Range: Function:
0 %* [0 - 100 %] The frequency converter sends the
value of this parameter to the
output terminal when the terminal
is controlled by a eldbus and a
timeout is detected.
3.29.6 36-5* Output X49/9
Use the parameters in this group to congure the mode of
inputs and outputs of VLT
®
Programmable I/O .
36-50 Terminal X49/9 Analogue Output
Select the functionality of terminal X49/9.
Option: Function:
[0] * No operation
[52] MCO 0-20mA/
0-10V
[86] Pressure
Sensor 1
[88] Pressure
Sensor 2
[93] Pressure
Sensor 3
36-50 Terminal X49/9 Analogue Output
Select the functionality of terminal X49/9.
Option: Function:
[100] Output freq.
0-100
[101] Reference
Min-Max
[102] Feedback
+-200%
[103] Motor cur. 0-
Imax
[104] Torque 0-Tlim
[105] Torque 0-
Tnom
[106] Power 0-Pnom
[107] Speed 0-
HighLim
[113] Ext. Closed
Loop 1
[114] Ext. Closed
Loop 2
[115] Ext. Closed
Loop 3
[121] Air pres. to
Flow
[139] Bus ctrl.
[141] Bus ctrl t.o.
[186] Pressure
Sensor 4
36-51 Terminal X49/9 Digital Output
Select the function of Terminal X49/9 as an analog voltage
output.
Option: Function:
[0] * No operation
[1] Control Ready
[2] Drive ready
[3] Drive rdy/rem
ctrl
[4] Standby / no
warning
[5] Running
[6] Running / no
warning
[8] Run on ref/no
warn
[9] Alarm
[10] Alarm or
warning
[11] At torque limit
[12] Out of current
range
[13] Below current,
low
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 267
3 3
