Danfoss vlt FC 102 Programming Guide

36-26 Term. X49/3 Filter Time Constant
Range: Function:
high value improves dampening
but also increases the delay
through the lter.
36-27 Term. X49/3 Live Zero
Enable live zero monitoring.
Option: Function:
[0] Disabled
[1] * Enabled
3.29.4 36-3* Analog Input X49/5
36-30 Terminal X49/5 Low Voltage
Range: Function:
0.07 V* [ 0 - par.
36-32 V]
Enter the voltage that corresponds
to the low reference value in
parameter 36-34 Term. X49/5 Low
Ref./Feedb. Value.
36-31 Terminal X49/5 Low Current
Range: Function:
4 mA* [ 0 - par.
36-33 mA]
Enter the current that corresponds
to the low reference value in
parameter 36-34 Term. X49/5 Low
Ref./Feedb. Value.
36-32 Terminal X49/5 High Voltage
Range: Function:
10 V* [ par. 36-30 -
10 V]
Enter the voltage that corresponds
to the high reference value in
parameter 36-35 Term. X49/5 High
Ref./Feedb. Value.
36-33 Terminal X49/5 High Current
Range: Function:
20 mA* [ par. 36-31 -
20 mA]
Enter the current that corresponds
to the high reference value in
parameter 36-35 Term. X49/5 High
Ref./Feedb. Value.
36-34 Term. X49/5 Low Ref./Feedb. Value
Range: Function:
0* [-999999.999
- 999999.999 ]
Enter the reference or feedback
value that corresponds to the
voltage or current value in
parameter 36-20 Terminal X49/3 Low
Voltage or parameter 36-21 Terminal
X49/3 Low Current.
36-35 Term. X49/5 High Ref./Feedb. Value
Range: Function:
100* [-999999.999
- 999999.999 ]
Enter the reference or feedback
value that corresponds to the
voltage or current value in
parameter 36-32 Terminal X49/5 High
Voltage or parameter 36-33 Terminal
X49/5 High Current.
36-36 Term. X49/5 Filter Time Constant
Range: Function:
0.005 s* [0.005 - 10 s] Enter the lter time constant. This
constant is a rst-order digital low-
pass lter time for suppressing
electrical noise in terminal X49/5. A
high value improves dampening
but also increases the delay
through the lter.
36-37 Term. X49/5 Live Zero
Option: Function:
[0] Disabled Enable live zero monitoring.
[1] * Enabled
3.29.5 36-4* Output X49/7
Use the parameters in this group to congure the mode of
inputs and outputs of VLT
®
Programmable I/O .
Select the functionality of terminal X49/7.
36-40 Terminal X49/7 Analogue Output
Option: Function:
[0] * No operation
[52] MCO 0-20mA/
0-10V
[86] Pressure
Sensor 1
[88] Pressure
Sensor 2
[93] Pressure
Sensor 3
[100] Output freq.
0-100
[101] Reference
Min-Max
[102] Feedback
+-200%
[103] Motor cur. 0-
Imax
[104] Torque 0-Tlim
[105] Torque 0-
Tnom
[106] Power 0-Pnom
Parameter Descriptions
VLT
®
HVAC Drive FC 102
264 Danfoss A/S © 10/2019 All rights reserved. M0010001
33
