0-21 Display Line 1.2 Small
Option: Function:
[1686] FC Port REF 1
[1687] Bus Readout
Alarm/Warning
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word
2
[1694] Ext. Status
Word
[1695] Ext. Status
Word 2
[1696] Maintenance
Word
[1697] Alarm Word 3
[1698] Warning Word
3
[1830] Analog Input
X42/1
[1831] Analog Input
X42/3
[1832] Analog Input
X42/5
[1833] Analog Out
X42/7 [V]
[1834] Analog Out
X42/9 [V]
[1835] Analog Out
X42/11 [V]
[1836] Analog Input
X48/2 [mA]
[1837] Temp. Input
X48/4
[1838] Temp. Input
X48/7
[1839] Temp. Input
X48/10
[1840] Analog Input
X49/1
[1841] Analog Input
X49/3
[1842] Analog Input
X49/5
[1843] Analog Out
X49/7
[1844] Analog Out
X49/9
[1845] Analog Out
X49/11
[1846] X49 Digital
Output [bin]
[1850] Sensorless
Readout [unit]
0-21 Display Line 1.2 Small
Option: Function:
[1857] Air Pressure to
Flow Air Flow
[1860] Digital Input 2
[1870] Mains Voltage
[1871] Mains
Frequency
[1872] Mains
Imbalance
[1875] Rectier DC
Volt.
[2117] Ext. 1
Reference
[Unit]
[2118] Ext. 1
Feedback
[Unit]
[2119] Ext. 1 Output
[%]
[2137] Ext. 2
Reference
[Unit]
[2138] Ext. 2
Feedback
[Unit]
[2139] Ext. 2 Output
[%]
[2157] Ext. 3
Reference
[Unit]
[2158] Ext. 3
Feedback
[Unit]
[2159] Ext. 3 Output
[%]
[2230] No-Flow
Power
[2316] Maintenance
Text
[2580] Cascade Status
[2581] Pump Status
[3110] Bypass Status
Word
[3111] Bypass
Running Hours
[3126] Pressure
Sensor 1
[3127] Pressure
Sensor 2
[3128] Pressure
Sensor 3
[3129] Pressure
Sensor 4
[3130] Press Sens
Cmp State
Parameter Descriptions Programming Guide
