0-21 Display Line 1.2 Small
Option: Function:
[3131] Press Sens
toggle
[3401] PCD 1 Write
to MCO
[3402] PCD 2 Write
to MCO
[3403] PCD 3 Write
to MCO
[3404] PCD 4 Write
to MCO
[3405] PCD 5 Write
to MCO
[3406] PCD 6 Write
to MCO
[3407] PCD 7 Write
to MCO
[3408] PCD 8 Write
to MCO
[3409] PCD 9 Write
to MCO
[3410] PCD 10 Write
to MCO
[3421] PCD 1 Read
from MCO
[3422] PCD 2 Read
from MCO
[3423] PCD 3 Read
from MCO
[3424] PCD 4 Read
from MCO
[3425] PCD 5 Read
from MCO
[3426] PCD 6 Read
from MCO
[3427] PCD 7 Read
from MCO
[3428] PCD 8 Read
from MCO
[3429] PCD 9 Read
from MCO
[3430] PCD 10 Read
from MCO
[9913] Idle time
[9914] Paramdb
requests in
queue
[9920] Fan Ctrl deltaT
[9921] Fan Ctrl
Tmean
[9922] Fan Ctrl NTC
Cmd
[9923] Fan Ctrl i-term
0-21 Display Line 1.2 Small
Option: Function:
[9924] Rectier
Current
[9952] PC Debug 0
[9953] PC Debug 1
[9954] PC Debug 2
[9961] FPC Debug 0
[9962] FPC Debug 1
[9963] FPC Debug 2
[9964] FPC Debug 3
[9965] FPC Debug 4
0-22 Display Line 1.3 Small
Select a variable for display in line 1, right position.
Option: Function:
[1610] * Power [kW] The options are the same as those listed in
parameter 0-20 Display Line 1.1 Small.
0-23 Display Line 2 Large
Select a variable for display in line 2.
Option: Function:
[1613] * Frequency The options are the same as those listed in
parameter 0-20 Display Line 1.1 Small.
0-24 Display Line 3 Large
Select a variable for display in line 3.
3.2.6 0-24 Display Line 3 Large
0-24 Display Line 3 Large
Option: Function:
[0] None
[15] Readout:
actual setup
[37] Display Text 1
[38] Display Text 2
[39] Display Text 3
[89] Date and Time
Readout
[953] Probus
Warning Word
[1005] Readout
Transmit Error
Counter
[1006] Readout
Receive Error
Counter
[1007] Readout Bus
O Counter
[1013] Warning
Parameter
[1115] LON Warning
Word
Parameter Descriptions
VLT
®
HVAC Drive FC 102
