Danfoss vlt FC 102 Programming Guide

3.2.4 0-2* LCP Display
Dene the variables shown in the LCP.
NOTICE
For information on how to write display texts, refer to:
•
Parameter 0-37 Display Text 1.
•
Parameter 0-38 Display Text 2.
•
Parameter 0-39 Display Text 3.
0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display in line
1, left position.
[0] None No display value selected
[15] Readout:
actual setup
[37] Display Text 1 Enables an individual text string to
be written, for showing in the LCP,
or to be read via serial communi-
cation.
[38] Display Text 2 Enables an individual text string to
be written, for showing in the LCP,
or to be read via serial communi-
cation.
[39] Display Text 3 Enables an individual text string to
be written, for showing in the LCP,
or to be read via serial communi-
cation.
[89] Date and Time
Readout
Shows the current date and time.
[953] Probus
Warning Word
Shows Probus communication
warnings.
[1005] Readout
Transmit Error
Counter
View the number of CAN control
transmission errors since the last
power-up.
[1006] Readout
Receive Error
Counter
View the number of CAN control
receipt errors since the last power-
up.
[1007] Readout Bus
O Counter
View the number of bus o-events
since the last power-up.
[1013] Warning
Parameter
View a DeviceNet-specic warning
word. 1 separate bit is assigned to
every warning.
[1115] LON Warning
Word
Shows the LON-specic warnings.
[1117] XIF Revision Shows the version of the external
interface le of the Neuron C chip
on the LON option.
0-20 Display Line 1.1 Small
Option: Function:
[1118] LonWorks
Revision
Shows the software version of the
application program of the Neuron
C chip on the LON option.
[1230] Warning
Parameter
[1397] Alert Alarm
Word
[1398] Alert Warning
Word
[1399] Alert Status
Word
[1500] Operating
hours
[1501] Running Hours View the number of running hours
of the motor.
[1502] kWh Counter View the mains power consumption
in kWh.
[1580] Fan Running
Hours
[1600] Control Word View the control word sent from
the frequency converter via the
serial communication port in hex
code.
[1601] Reference
[Unit]
Total reference (sum of digital/
analog/preset/bus/freeze ref./catch
up and slow-down) in selected unit.
[1602] * Reference [%] Total reference (sum of digital/
analog/preset/bus/freeze ref./catch
up and slow-down) in percent.
[1603] Status Word Present status word
[1605] Main Actual
Value [%]
View the 2-byte word sent with the
status word to the bus master
reporting the main actual value.
[1609] Custom
Readout
View the user-dened readouts as
dened in
•
Parameter 0-30 Custom
Readout Unit,
•
Parameter 0-31 Custom
Readout Min Value,
•
Parameter 0-32 Custom
Readout Max Value.
[1610] Power [kW] Actual power consumed by the
motor in kW.
[1611] Power [hp] Actual power consumed by the
motor in hp.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Frequency Motor frequency, that is the output
frequency from the frequency
converter in Hz.
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 31
3 3

Danfoss vlt FC 102 Specifications

General

Category	DC Drives
Model	Danfoss VLT FC 102
Output voltage range	0 to rated motor voltage
Power range	0.37 kW to 200 kW
Communication interfaces	RS-485
Protection features	Overvoltage, undervoltage, overcurrent, short circuit, earth fault, overtemperature, motor thermal protection
Cooling method	Air-cooled
Enclosure rating	IP20, IP21, IP55 (depending on model)
Approvals	CE, UL, cUL
