0-30 Custom Readout Unit
Option: Function:
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[174] in Hg
[180] HP
0-31 Custom Readout Min Value
Range: Function:
Size
related*
[ -999999.99 -
100.00
CustomRea-
doutUnit]
This parameter allows selection of
the minimum value of the custom-
dened readout (occurs at 0 speed).
It is only possible to select a value
dierent from 0 when selecting a
linear unit in parameter 0-30 Custom
Readout Unit. For quadratic and
0-31 Custom Readout Min Value
Range: Function:
cubic units, the minimum value is
0.
0-32 Custom Readout Max Value
Range: Function:
100
Custom-
ReadoutUni
t*
[ par. 0-31 -
999999.99
CustomRea-
doutUnit]
This parameter sets the maximum
value to be shown when the speed
of the motor has reached the set
value for parameter 4-13 Motor
Speed High Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed Unit).
0-37 Display Text 1
Range: Function:
0* [0 - 25 ] In this parameter, it is possible to
write an individual text string to be
shown in the LCP or to be read via
serial communication.
To show the text permanently,
select [37] Display Text 1 in 1 of the
following parameters:
•
Parameter 0-20 Display Line
1.1 Small.
•
Parameter 0-21 Display Line
1.2 Small.
•
Parameter 0-22 Display Line
1.3 Small.
•
Parameter 0-23 Display Line
2 Large.
•
Parameter 0-24 Display Line
3 Large.
•
Parameter 0-37 Display Text
1.
Changing parameter 12-08 Host
Name changes
parameter 0-37 Display Text 1 - but
not the opposite way.
