Danfoss vlt FC 102 Operating Guide

1.
2.
3.
4.
5.

6.
7.
1.
2.

•
•
•
•
•
•
•
1.
5.2.6.1 Recommended Initialization
Procedure
Press [Main Menu] twice to access parameter.
Scroll to parameter 14-22 Operation Mode and press [OK].
Scroll to [2] Initialisation and press [OK].
Remove power to the unit and wait for the display to turn off.
Apply power to the unit.
Default parameter settings are restored during start-up. This may take slightly longer than normal.
Alarm 80, Drive initialised is shown.
Press [Reset] to return to operating mode.
5.2.6.2 Manual Initialization
Procedure
Remove power to the unit and wait for the display to turn off.
Press and hold [Status], [Main Menu], and [OK] at the same time while applying power to the unit (approximately 5 s or until
a click is heard and the fan starts).
Factory default parameter settings are restored during start-up. This might take slightly longer than normal.
Manual initialization resets parameter settings except for the settings in:
Parameter 15-00 Operating Hours.
Parameter 15-03 Power Up's.
Parameter 15-04 Over Temp's.
Parameter 15-05 Over Volt's.
5.3 Basic Programming
5.3.1 Commissioning with SmartStart
The SmartStart wizard enables fast configuration of basic motor and application parameters.
N O T I C E
Motor data is required for the SmartStart setup. The required data are normally available on the motor nameplate.
At 1st power-up or after initialization of the drive, SmartStart starts automatically.
Follow the on-screen instructions to complete commissioning of the drive. Always reactivate SmartStart by selecting Quick
Menu Q4 - SmartStart.
For commissioning without using the SmartStart wizard, refer to
5.3.2 Commissioning via [Main Menu] or the Programming
Guide.
5.3.2 Commissioning via [Main Menu]
Recommended parameter settings are intended for start-up and checkout purposes. Application settings may vary.
Enter data with power ON, but before operating the drive.
Procedure
Press [Main Menu] on the LCP.
AQ267037536117en-000101 / 130R0083 | 41Danfoss A/S © 2023.09
Commissioning
VLT HVAC Drive FC 102
Operating Guide
