Page #98 background image
Enclosure
Mains
Motor
Brake
Loadshare
Disconnect
B2
35(2)
35(2)
35(2)
35(2)
35(2)
B3
10(7)
10(7)
10(7)
10(7)
10(7)
B4
35(2)
35(2)
35(2)
35(2)
35(2)
C1
50(1/0)
50(1/0)
50(1/0)
50(1/0)
50(1/0)
C2
95(4/0)
95(4/0)
95(4/0)
95(4/0)
95(4/0)
C3
50(1/0)
50(1/0)
50(1/0)
50(1/0)
50(1/0)
C4
95(4/0)
95(4/0)
95(4/0)
95(4/0)
95(4/0)
8.8.3 Control Cable Cross-sections
Maximum cross-section to control terminals, flexible/rigid wire
without cable end sleeves
1.5 mm
2
/16 AWG
Maximum cross-section to control terminals, flexible wire with ca-
ble end sleeves
1 mm
2
/18 AWG
Maximum cross-section to control terminals, flexible wire with ca-
ble end sleeves with collar
0.5 mm
2
/20 AWG
Minimum cross-section to control terminals
0.25 mm
2
/24 AWG
8.9 Control Input/Output and Control Data
8.9.1 Digital Inputs
Programmable digital inputs
(1)
4 (6)
Terminal number
18, 19, 27, 29, 32, 33
Voltage level
0–24 V
Voltage level, logic 0 PNP
<5 V DC
Voltage level, logic 1 PNP
>10 V DC
Voltage level, logic 0 NPN
>19 V DC
Voltage level, logic 1 NPN
<14 V DC
Maximum voltage on input
28 V DC
Pulse frequency range
0–110 kHz
(Duty cycle) Minimum pulse width
4.5 ms
Input resistance, R
i
Approximately 4 kΩ
1
The digital input is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
8.9.2 STO Terminal 37 (Terminal 37 is Fixed PNP Logic)
Voltage level
0–24 V DC
Voltage level, logic 0 PNP
<4 V DC
Voltage level, logic 1 PNP
>20 V DC
Maximum voltage on input
28 V DC
Typical input current at 24 V
50 mA rms
Typical input current at 20 V
60 mA rms
Input capacitance
400 nF
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
See 4.8.7 Safe Torque Off (STO) for further information about terminal 37 and Safe Torque Off.
AQ267037536117en-000101 / 130R008398 | Danfoss A/S © 2023.09
Specifications
VLT HVAC Drive FC 102
Operating Guide
