Type designation
P18K
P22K
P30K
P37K
P45K
Continuous (3x200–240 V) [A]
68
80
104
130
154
Intermittent (3x200–240 V) [A]
74.8
88
114
143
169
SCCR
With mains disconnect [kA
rms
]
65 kA
65 kA
10 kA
10 kA
10 kA
Without mains disconnect [kA
rms
]
100 kA
100 kA
100 kA
100 kA
100 kA
Power losses and efficiency
Estimated power loss at rated maximum load [W]
(2)
737
845
1140
1353
1636
Efficiency
(3)
0.96
0.97
0.97
0.97
0.97
1
B3+4 and C3+4 may be converted to IP21 using a conversion kit.
2
The typical power loss is at normal load conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions).
Values are based on a typical motor efficiency. Lower efficiency motors also add to the power loss in the drive and conversely. If the switching fre-
quency is raised from nominal, the power losses may rise significantly. LCP and typical control card power consumptions are included. Further op-
tions and customer load may add up to 30 W to the losses. (Though typically only 4 W extra for a fully loaded control card or options for slot A or slot
B, each). Although measurements are made with state-of-the-art equipment, some measurement inaccuracy must be allowed for (±5%).
3
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency.
8.2 Electrical Data, 380–480 V and 3x220Y/380–277Y/480 V
Table 46: Mains Supply 3x380–480 V AC and 3x220Y/380–277Y/480 V AC, Normal Overload 110% for 1 minute, P1K1–P7K5
Type designation
P1K1
P1K5
P2K2
P3K0
P4K0
P5K5
P5K5
Typical shaft output [kW]
1.1
1.5
2.2
3.0
4.0
5.5
7.5
Typical shaft output at 460 V [hp]
1.5
2.0
2.9
4.0
5.0
7.5
10
IP20/UL Open Type
(1)
A2
A2
A2
A2
A2
A3
A3
IP55/UL Type 12
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A5
A5
IP66/UL Type 4X
A4/A5
A4/A5
A4/A5
A4/A5
A4/A5
A5
A5
Output current
Continuous (3x380–440 V) [A]
3
4.1
5.6
7.2
10
13
16
Intermittent (3x380–440 V) [A]
3.3
4.5
6.2
7.9
11
14.3
17.6
Continuous (3x441–480 V) [A]
2.7
3.4
4.8
6.3
8.2
11
14.5
Intermittent (3x441–480 V) [A]
3.0
3.7
5.3
6.9
9.0
12.1
15.4
Continuous kVA (400 V AC) [kVA]
2.1
2.8
3.9
5.0
6.9
9.0
11
Continuous kVA (460 V AC) [kVA]
2.4
2.7
3.8
5.0
6.5
8.8
11.6
Maximum input current
Continuous (3x380–440 V) [A]
2.7
3.7
5.0
6.5
9.0
11.7
14.4
Intermittent (3x380–440 V) [A]
3.0
4.1
5.5
7.2
9.9
12.9
15.8
Continuous (3x441–480 V) [A]
2.7
3.1
4.3
5.7
7.4
9.9
13
Intermittent (3x441–480 V) [A]
3.0
3.4
4.7
6.3
8.1
10.9
14.3
AQ267037536117en-000101 / 130R0083 | 87Danfoss A/S © 2023.09
