Danfoss vlt FC 102 Operating Guide

Type designation
P5K5
P7K5
P11K
P15K
IP55/UL Type 12
B1
B1
B1
B2
IP66/UL Type 4X
B1
B1
B1
B2
Output current
Continuous (3x200–240 V) [A]
24.2
30.8
46.2
59.4
Intermittent (3x200–240 V) [A]
26.6
33.9
50.8
65.3
Continuous kVA (208 V AC) [kVA]
8.7
11.1
16.6
21.4
Maximum input current
Continuous (3x200–240 V) [A]
22
28
42
54
Intermittent (3x200–240 V) [A]
24.2
30.8
46.2
59.4
SCCR
With mains disconnect [kA
rms
]
65 kA
65 kA
65 kA
10 kA
Without mains disconnect [kA
rms
]
100 kA
100 kA
100 kA
100 kA
Power losses and efficiency
Estimated power loss at rated maximum load [W]
(2)
269
310
447
602
Efficiency
(3)
0.96
0.96
0.96
0.96
1
B3+4 and C3+4 may be converted to IP21 using a conversion kit.
2
The typical power loss is at normal load conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions).
Values are based on a typical motor efficiency. Lower efficiency motors also add to the power loss in the drive and conversely. If the switching fre-
quency is raised from nominal, the power losses may rise significantly. LCP and typical control card power consumptions are included. Further op-
tions and customer load may add up to 30 W to the losses. (Though typically only 4 W extra for a fully loaded control card or options for slot A or slot
B, each). Although measurements are made with state-of-the-art equipment, some measurement inaccuracy must be allowed for (±5%).
3
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency.
Table 45: Mains Supply 3x200–240 V AC and 3x115Y/200–139Y/240 V AC, Normal Overload 110% for 1 minute, P18K–P45K
Type designation
P18K
P22K
P30K
P37K
P45K
Typical shaft output [kW]
18.5
22
30
37
45
Typical shaft output at 208 V [hp]
25
30
40
50
60
IP20/UL Open Type
(1)
B4
C3
C3
C4
C4
IP21/UL Type 1
C1
C1
C1
C2
C2
IP55/UL Type 12
C1
C1
C1
C2
C2
IP66/UL Type 4X
C1
C1
C1
C2
C2
Output current
Continuous (3x200–240 V) [A]
74.8
88
115
143
170
Intermittent (3x200–240 V) [A]
82.3
96.8
127
157
187
Continuous kVA (208 V AC) [kVA]
26.9
31.7
41.4
51.5
61.2
Maximum input current
AQ267037536117en-000101 / 130R008386 | Danfoss A/S © 2023.09
Specifications
VLT HVAC Drive FC 102
Operating Guide
