Danfoss vlt FC 102 Operating Guide

Type designation
P1K1
P1K5
P2K2
P3K0
P4K0
P5K5
P5K5
SCCR
A2/A3 with mains disconnect [kA
rms
]
50 kA
50 kA
50 kA
50 kA
50 kA
50 kA
50 kA
A4/A5 with mains disconnect [kA
rms
]
65 kA
65 kA
65 kA
65 kA
65 kA
65 kA
65 kA
Without mains disconnect [kA
rms
]
100 kA
100 kA
100 kA
100 kA
100 kA
100 kA
100 kA
Power losses and efficiency
Estimated power loss at rated maximum load [W]
(2)
58
62
88
116
124
187
255
Efficiency
(3)
0.96
0.97
0.97
0.97
0.97
0.97
0.97
1
A2+A3 may be converted to IP21 using a conversion kit.
2
The typical power loss is at normal load conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions).
Values are based on a typical motor efficiency. Lower efficiency motors also add to the power loss in the drive and vice versa. If the switching fre-
quency is raised from nominal, the power losses may rise significantly. LCP and typical control card power consumptions are included. Further op-
tions and customer load may add up to 30 W to the losses. (Though typically only 4 W extra for a fully-loaded control card or options for slot A or slot
B, each). Although measurements are made with state-of-the-art equipment, some measurement inaccuracy must be allowed for (±5%).
3
Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency.
Table 47: Mains Supply 3x380–480 V AC and 3x220Y/380–277Y/480 V AC, Normal Overload 110% for 1 minute, P11K–P30K
Type designation
P11K
P15K
P18K
P22K
P30K
Typical shaft output [kW]
11
15
18.5
22
30
Typical shaft output at 460 V [hp]
15
20
25
30
40
IP20/UL Open Type
(1)
B3
B3
B3
B4
B4
IP21/UL Type 1
B1
B1
B1
B2
B2
IP55/UL Type 12
B1
B1
B1
B2
B2
IP66/UL Type 4X
B1
B1
B1
B2
B2
Output current
Continuous (3x380–439 V) [A]
24
32
37.5
44
61
Intermittent (3x380–439 V) [A]
26.4
35.2
41.3
48.4
67.1
Continuous (3x440–480 V) [A]
21
27
34
40
52
Intermittent (3x440–480 V) [A]
23.1
29.7
37.4
44
61.6
Continuous kVA (400 V AC) [kVA]
16.6
22.2
26
30.5
42.3
Continuous kVA (460 V AC) [kVA]
16.7
21.5
27.1
31.9
41.4
Maximum input current
Continuous (3x380–439 V) [A]
22
29
34
40
55
Intermittent (3x380–439 V) [A]
24.2
31.9
37.4
44
60.5
Continuous (3x440–480 V) [A]
19
25
31
36
47
Intermittent (3x440–480 V) [A]
20.9
27.5
34.1
39.6
51.7
SCCR
AQ267037536117en-000101 / 130R008388 | Danfoss A/S © 2023.09
Specifications
VLT HVAC Drive FC 102
Operating Guide

Danfoss vlt FC 102 Specifications

General

Category	DC Drives
Model	Danfoss VLT FC 102
Output voltage range	0 to rated motor voltage
Power range	0.37 kW to 200 kW
Communication interfaces	RS-485
Protection features	Overvoltage, undervoltage, overcurrent, short circuit, earth fault, overtemperature, motor thermal protection
Cooling method	Air-cooled
Enclosure rating	IP20, IP21, IP55 (depending on model)
Approvals	CE, UL, cUL
