Power losses and efficiency
Estimated power loss at rated maximum load [W]
(1)
1
The typical power loss is at normal load conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions).
Values are based on a typical motor efficiency. Lower efficiency motors also add to the power loss in the drive and conversely. If the switching fre-
quency is raised from nominal, the power losses may rise significantly. LCP and typical control card power consumptions are included. Further op-
tions and customer load may add up to 30 W to the losses. (Though typically only 4 W extra for a fully loaded control card or options for slot A or slot
B, each). Although measurements are made with state-of-the-art equipment, some measurement inaccuracy must be allowed for (±5%).
2
Measured using 5m (16.4 ft) shielded motor cables at rated load and rated frequency
Table 50: Mains Supply 3x525–600 V AC - Normal Overload 110% for 1 Minute, P11K–P30K
Typical shaft output [kW]
Continuous (3x525–550 V) [A]
Intermittent (3x525–550 V) [A]
Continuous (3x525–600 V) [A]
Intermittent (3x525–600 V) [A]
Continuous kVA (525 V AC) [kVA]
Continuous kVA (575 V AC) [kVA]
Continuous (3x525–600 V) [A]
Intermittent (3x525–600 V) [A]
With mains disconnect [kA
rms
]
Without mains disconnect [kA
rms
]
AQ267037536117en-000101 / 130R0083 | 91Danfoss A/S © 2023.09
Specifications
VLT HVAC Drive FC 102
Operating Guide
