4.4.1 In-line Connection (Bypassed)
NOTICE
Models MCD5-0021B to MCD5-0961B are internally bypassed. Models MCD5-0245C to MCD5-1600C require an external
bypass contactor.
Type code Ampere rating [A]
AC-53b
3-30:330
AC-53b
4-20:340
AC-53b
4.5-30:330
MCD5-0021B 21 17 15
MCD5-0037B 37 31 26
MCD5-0043B 43 37 30
MCD5-0053B 53 46 37
AC-53b
3-30:570
AC-53b
4-20:580
AC-53b
4.5-30:570
MCD5-0068B 68 55 47
MCD5-0084B 84 69 58
MCD5-0089B 89 74 61
MCD5-0105B 105 95 78
MCD5-0131B 131 106 90
MCD5-0141B 141 121 97
MCD5-0195B 195 160 134
MCD5-0215B 215 178 148
MCD5-0245B 245 194 169
MCD5-0245C 255 201 176
MCD5-0331B 331 266 229
MCD5-0360C 360 310 263
MCD5-0380C 380 359 299
MCD5-0396B 396 318 273
MCD5-0428C 430 368 309
MCD5-0469B 496 383 326
MCD5-0525B 525 425 364
MCD5-0595C 620 540 434
MCD5-0619C 650 561 455
MCD5-0632B 632 512 438
MCD5-0790C 790 714 579
MCD5-0744B 744 606 516
MCD5-0826B 826 684 571
MCD5-0927C 930 829 661
MCD5-0961B 961 796 664
MCD5-1200C 1200 1200 1071
MCD5-1410C 1410 1319 1114
MCD5-1600C 1600 1600 1353
Table 4.2 Internally Bypassed Models
