Danfoss vlt soft starter mcd 500 - Bussmann Fuses

4.10.2 Bussmann Fuses
Model
SCR I
2
t (A
2
s)
Supply voltage
(≤440 V AC)
Supply voltage
(≤575 V AC)
Supply voltage
(≤690 V AC)
MCD5-0021B 1150 170M1314 170M1314 170M1314
MCD5-0037B 8000 170M1316 170M1316 170M1316
MCD5-0043B 10500 170M1318 170M1318 170M1318
MCD5-0053B 15000 170M1318 170M1318 170M1318
MCD5-0068B 15000 170M1319 170M1319 170M1318
MCD5-0084B 512000 170M1321 170M1321 170M1319
MCD5-0089B 80000 170M1321 170M1321 170M1321
MCD5-0105B 125000 170M1321 170M1321 170M1321
MCD5-0131B 125000 170M1321 170M1321 170M1321
MCD5-0141B 320000 170M2621 170M2621 170M2621
MCD5-0195B 320000 170M2621 170M2621 170M2621
MCD5-0215B 320000 170M2621 170M2621 170M2621
MCD5-0245B 320000 170M2621 170M2621 170M2621
MCD5-0331B 202000 170M5011 170M5011 –
MCD5-0396B 320000 170M6011 – –
MCD5-0469B 320000
170M6008
1)
– –
MCD5-0525B 781000 170M6013 170M6013 170M6013
MCD5-0632B 781000 170M5015 170M5015 –
MCD5-0744B 1200000 170M5017 170M6017 –
MCD5-0826B 2530000 170M6017 170M6017 –
MCD5-0961B 2530000 170M6018
170M6013
1)
–
MCD5-0245C 320000 170M2621 170M2621 170M2621
MCD5-0360C 320000 170M6010 170M6010 170M6010
MCD5-0380C 320000 170M6011 170M6011 –
MCD5-0428C 320000 170M6011 170M6011 –
MCD5-0595C 1200000 170M6015 170M6015 170M6014
MCD5-0619C 1200000 170M6015 170M6015 170M6014
MCD5-0790C 2530000 170M6017 170M6017 170M6016
MCD5-0927C 4500000 170M6019 170M6019 170M6019
MCD5-1200C 4500000 170M6021 – –
MCD5-1410C 6480000 – – –
MCD5-1600C 12500000
170M6019
1)
– –
Table 4.7 Square Body (170M)
1) Two fuses connected in parallel are required per phase.
