Model
SCR I
2
t (A
2
s)
Supply voltage
(<440 V AC)
Supply voltage
(<575 V AC)
Supply voltage
(<690 V AC)
MCD5-0021B 1150 63FE 63FE 63FE
MCD5-0037B 8000 120FEE 120FEE 120FEE
MCD5-0043B 10500 120FEE 120FEE 120FEE
MCD5-0053B 15000 200FEE 200FEE 200FEE
MCD5-0068B 15000 200FEE 200FEE 200FEE
MCD5-0084B 512000 200FEE 200FEE 200FEE
MCD5-0089B 80000 280FM 280FM 280FM
MCD5-0105B 125000 280FM 280FM 280FM
MCD5-0131B 125000 280FM 280FM 280FM
MCD5-0141B 320000 450FMM 450FMM 450FMM
MCD5-0195B 320000 450FMM 450FMM 450FMM
MCD5-0215B 320000 450FMM 450FMM 450FMM
MCD5-0245B 320000 450FMM 450FMM 450FMM
MCD5-0331B 202000
315FM
1)
– –
MCD5-0396B 320000
400FMM
1)
– –
MCD5-0469B 320000
450FMM
1)
– –
MCD5-0525B 781000
500FMM
1)
500FMM
1)
500FMM
1)
MCD5-0632B 781000
630FMM
1)
– –
MCD5-0744B 1200000 – – –
MCD5-0826B 2530000 – – –
MCD5-0961B 2530000 – – –
MCD5-0245C 320000 450FMM 450FMM 450FMM
MCD5-0360C 320000 – – –
MCD5-0380C 320000
400FMM
1)
400FMM
400FMM
1)
MCD5-0428C 320000 – – –
MCD5-0595C 1200000
630FMM
1)
630FMM
1)
–
MCD5-0619C 1200000
630FMM
1)
630FMM
1)
–
MCD5-0790C 2530000 – – –
MCD5-0927C 4500000 – – –
MCD5-1200C 4500000 – – –
MCD5-1410C 6480000 – – –
MCD5-1600C 12500000 – – –
Table 4.8 British Style (BS88)
1) Two fuses connected in parallel are required per phase.
