11 Specications
Supply
Mains voltage (L1, L2, L3)
MCD5-xxxx-T5 200–525 V AC (±10%)
MCD5-xxxx-T7 380–690 V AC (±10%) (in-line connection)
MCD5-xxxx-T7 380–600 V AC (±10%) (inside delta connection)
Control voltage (A4, A5, A6)
CV1 (A5, A6) 24 V AC/V DC (±20%)
CV2 (A5, A6) 110–120 V AC (+10%/-15%)
CV2 (A4, A6) 220–240 V AC (+10%/-15%)
Current consumption (maximum)
CV1 2.8 A
CV2 (110–120 V AC) 1 A
CV2 (220–240 V AC) 500 mA
Mains frequency 45–66 Hz
Rated insulation voltage to ground 600 V AC
Rated impulse withstand voltage 4 kV
Form designation Bypassed or continuous, semiconductor motor starter form 1
Short circuit capability (IEC)
Coordination with semiconductor fuses Type 2
Coordination with HRC fuses Type 1
MCD5-0021B to MCD5-0215B Prospective current 65 kA
MCD5-0245B to MCD5-0961B Prospective current 85 kA
MCD5-0245C to MCD5-0927B Prospective current 85 kA
MCD5-1200C to MCD5-1600C Prospective current 100 kA
For UL short-circuit current ratings, see Table 4.12.
Electromagnetic capability (compliant with EU Directive 89/336/EEC)
EMC emissions IEC 60947-4-2 Class B and Lloyds Marine No 1 Specication
EMC immunity IEC 60947-4-2
Inputs
Input rating Active 24 V DC, 8 mA approximately
Start (15, 16) Normally open
Stop (17, 18) Normally closed
Reset (25, 18) Normally closed
Programmable input (11, 16) Normally open
Motor thermistor (05, 06) Trip >3.6 kΩ, reset <1.6 kΩ
Outputs
Relay outputs 10 A @ 250 V AC resistive, 5 A @ 250 V AC AC15 pf 0.3
Programmable outputs
Relay A (13, 14) Normally open
Relay B (21, 22, 24) Changeover
Relay C (33, 34) Normally open
Analog output (07, 08) 0–20 mA or 4–20 mA (selectable)
Maximum load 600 Ω (12 V DC @ 20 mA)
Accuracy ±5%
24 V DC output (16, 08) maximum load 200 mA
Accuracy ±10%
