7-12 Adaptive Control Gain-2
Range: Function:
75%* [1–200%] Adjusts the performance of adaptive control.
The setting aects both starting and stopping
control.
NOTICE
Leave the gain setting at the default
level unless adaptive control
performance is not satisfactory.
If the motor accelerates or decelerates
quickly at the end of a start or stop,
increase the gain setting by 5–10%. If
the motor speed uctuates during
starting or stopping, decrease the gain
setting slightly.
7-13 Adaptive Start Prole-2
Option: Function:
Selects which prole the soft starter
uses for an adaptive control soft start.
Early acceleration
Constant acceleration*
Late acceleration
7-14 Adaptive Stop Prole-2
Option: Function:
Selects which prole the soft starter
uses for an adaptive control soft stop.
Early deceleration
Constant deceleration*
Late acceleration
7-15 Brake Torque-2
Range: Function:
20%* [20–100%] Sets the amount of brake torque the soft
starter uses to slow the motor.
7-16 Brake Time-2
Range: Function:
1 s* [1–30 s]
NOTICE
This parameter is used with parameter
7-11 Stop Time-2.
Sets the duration for DC injection during a
braking stop.
8.8 Display
8-1 Language
Option: Function:
Selects in which language the LCP
shows messages and feedback.
English*
Chinese (中丈)
Spanish (Español)
German (Deutsch)
Portuguese (Português)
8-1 Language
Option: Function:
French (Français)
Italian (Italiano)
Russian (Русский)
8.8.1 User-programmable Screen
Selects which 4 items to show on the programmable
monitoring screen.
8-2 User Screen - Top Left
Option: Function:
Selects the item shown in the top left part of
the screen.
Blank Shows no data in the selected area, allowing
long messages to be shown without
overlapping.
Starter state The operating state of the soft starter (starting,
running, stopping, or tripped). Only available
for Top L and Btm L.
Motor current The average current measured on 3 phases.
Motor pf* The motor power factor measured by the soft
starter.
Mains
frequency
The average frequency measured on 3 phases.
Motor kW The motor running power in kW.
Motor hp The motor running power in horse power.
Motor temp The motor temperature, calculated by the
thermal model.
kWh The number of kWh the motor has run via the
soft starter.
Hours run The number of hours the motor has run via
the soft starter.
8-3 User Screen - Top Right
Option: Function:
Selects the item shown in the top right part of
the screen.
Blank* Shows no data in the selected area, allowing
long messages to be shown without
overlapping.
Starter state The operating state of the soft starter (starting,
running, stopping, or tripped). Only available
for Top L and Btm L.
Motor current The average current measured on 3 phases.
Motor pf The motor power factor measured by the soft
starter.
Mains
frequency
The average frequency measured on 3 phases.
Motor kW The motor running power in kW.
Motor hp The motor running power in horse power.
Motor temp The motor temperature, calculated by the
thermal model.
