4.10.3 Ferraz Fuses
Model
SCR I
2
t (A
2
s)
Supply voltage
(<440 V AC)
Supply voltage
(<575 V AC)
Supply voltage
(<690 V AC)
MCD5-0021B 1150
HSJ40
1)
HSJ40
1)
Not applicable
MCD5-0037B 8000
HSJ80
1)
HSJ80
1)
MCD5-0043B 10500
HSJ90
1)
HSJ90
1)
MCD5-0053B 15000
HSJ110
1)
HSJ110
1)
MCD5-0068B 15000
HSJ125
1)
HSJ125
1)
MCD5-0084B 51200 HSJ175
HSJ175
1)
MCD5-0089B 80000 HSJ175 HSJ175
MCD5-0105B 125000 HSJ225 HSJ225
MCD5-0131B 125000 HSJ250
HSJ250
1)
MCD5-0141B 320000 HSJ300 HSJ300
MCD5-0195B 320000 HSJ350 HSJ350
MCD5-0215B 320000
HSJ400
1)
HSJ400
1)
MCD5-0245B 320000
HSJ450
1)
HSJ450
1)
MCD5-0331B 202000
HSJ500
1)
Not applicable
MCD5-0396B 320000
Not applicable
MCD5-0469B 320000
MCD5-0525B 781000
MCD5-0632B 781000
MCD5-0744B 1200000
MCD5-0826B 2530000
MCD5-0961B 2530000
MCD5-0245C 320000
HSJ450
1)
HSJ450
1)
MCD5-0360C 320000
Not applicable Not applicable
MCD5-0380C 320000
MCD5-0428C 320000
MCD5-0595C 1200000
MCD5-0619C 1200000
MCD5-0790C 2530000
MCD5-0927C 4500000
MCD5-1200C 4500000
MCD5-1410C 6480000
MCD5-1600C 12500000
Table 4.9 HSJ
1) 2 series connected fuses required per phase.
