11.1.5 Models MCD5-0360C to
MCD5-1600C
•
Congure the busbars for line/load terminals at
opposite ends of the soft starter (that is Top in/
Bottom out, or Top out/Bottom in.
•
Use the recommended pressure terminal/
connector kit. See Table 11.1 for more
information.
11.1.6 Models MCD5-0469B to
MCD5-0961B
These models are UL-recognized components. Separate
cable landing busbars may be required within the electrical
cabinet when terminating cables sized according to the
National Wiring Code (NEC) regulations.
11.1.7 Pressure Terminal/Connector Kits
For models MCD50131B to MCD5-0396B and MCD5-0245C
to MCD5-1600C to be UL-compliant, use the recommended
pressure terminal/connector as detailed in Table 11.1.
Model FLC (A)
Number of
wires
Recommended
lugs ordering
numbers
MCD5-0131B 145 1 OPHD 95-16
MCD5-0141B 170 1 OPHD 120-16
MCD5-0195B 200 1 OPHD 150-16
MCD5-0215B 220 1 OPHD 185-16
MCD5-0245B 255 1 OPHD 240-20
MCD5-0331B 350 1 OPHD 400-16
MCD5-0396B 425 2 OPHD 185-16
MCD5-0245C 255 1 OPHD 240-20
MCD5-0360C 360
2 1 x 600T-2
MCD5-0380C 380
MCD5-0428C 430
MCD5-0595C 620
MCD5-0619C 650
MCD5-0790C 790 4 2 x 600T-2
MCD5-0927C 930 3 2 x 600T-2
MCD5-1200C 1200
4 1 x 750T-4
MCD5-1410C 1410
MCD5-1600C 1600 5
1 x 750T-4 and
1 x 600T-3
Table 11.1 Pressure Terminal/Connector Kits
11.2
Accessories
11.2.1 LCP Remote Mounting Kit
The VLT
®
Soft Starter MCD 500 LCP can be mounted up to
3 m away from the soft starter, allowing remote control
and monitoring. The remote LCP also allows parameter
settings to be copied between soft starters.
•
175G0096 Control Panel LCP 501.
11.2.2 Communication Modules
VLT
®
Soft Starter MCD 500 supports network communi-
cation via easy-to-install communication modules. Each
soft starter can support 1 communication module at a
time.
Available protocols:
•
Ethernet (PROFINET, Modbus TCP, EtherNet/IP).
•
PROFIBUS.
•
DeviceNet.
•
Modbus RTU.
•
USB.
Ordering numbers for communication modules
•
175G9000 Modbus module.
•
175G9001 PROFIBUS module.
•
175G9002 DeviceNet module.
•
175G9009 MCD USB module
•
175G9904 Modbus TCP module.
•
175G9905 PROFINET module.
•
175G9906 EtherNet/IP module.
11.2.3 PC Software
WinMaster PC software provides:
•
Monitoring.
•
Programming.
•
Control of up to 99 soft starters.
A Modbus or USB communication module is required for
each soft starter to use WinMaster.
Specications
VLT
®
Soft Starter MCD 500
