5.6 Inside Delta Operation
Adaptive control, jog, and brake functions are not
supported in inside delta (6-wire) operation. If these
functions are programmed when the soft starter is
connected inside delta, the behavior is as in Table 5.2:
Adaptive
control
start
The soft starter performs a constant current start.
Adaptive
control
stop
If stop time is >0 s, the starter performs a TVR soft
stop. If stop time is set to 9 s, the starter performs a
coast to stop.
Jog The soft starter issues a warning with the error
message Unsupported Option.
Brake The starter performs a coast to stop.
Table 5.2 Inside Delta Behavior at Adaptive Control, Jog,
and Brake
NOTICE
When connected in inside delta, current imbalance is the
only phase loss protection that is active during run. Do
not disable parameter 2-2 Current Imbalance during
inside delta operation.
NOTICE
Inside delta operation is only possible with mains
voltage ≤600 V AC.
5.7 Typical Start Currents
To determine the typical start current for an application,
use this information.
NOTICE
These start current requirements are appropriate and
typical in most circumstances. However, the performance
and start torque requirements of motors and machines
do vary. For further assistance, contact the local Danfoss
supplier.
General and water
Agitator 4.0 FLC
Centrifugal pump 3.5 x FLC
Compressor (screw, unloaded) 3.0 x FLC
Compressor (reciprocating, unloaded) 4.0 x FLC
Conveyor 4.0 x FLC
Fan (damped) 3.5 x FLC
Fan (undamped) 4.5 x FLC
Mixer 4.5 x FLC
Positive displacement pump 4.0 x FLC
Submersible pump 3.0 x FLC
Table 5.3 Typical Start Currents for General and Water
Applications
Metals and mining
Belt conveyor 4.5 x FLC
Dust collector 3.5 x FLC
Grinder 3.0 x FLC
Hammer mill 4.5 x FLC
Rock crusher 4.0 x FLC
Roller conveyor 3.5 x FLC
Roller mill 4.5 x FLC
Tumbler 4.0 x FLC
Wire draw-machine 5.0 x FLC
Table 5.4 Typical Start Currents for Metals and Mining
Applications
Food processing
Bottle washer 3.0 x FLC
Centrifuge 4.0 x FLC
Dryer 4.5 x FLC
Mill 4.5 x FLC
Palletizer 4.5 x FLC
Separator 4.5 x FLC
Slicer 3.0 x FLC
Table 5.5 Typical Start Currents for Food Processing
Applications
Pulp and paper
Dryer 4.5 x FLC
Repulper 4.5 x FLC
Shredder 4.5 x FLC
Table 5.6 Typical Start Currents for Pulp and Paper Applications
Petrochemical
Ball mill 4.5 x FLC
Centrifuge 4.0 x FLC
Extruder 5.0 x FLC
Screw conveyor 4.0 x FLC
Table 5.7 Typical Start Currents for Petrochemical Applications
Transport and machine tool
Ball mill 4.5 x FLC
Grinder 3.5 x FLC
Material conveyor 4.0 x FLC
Palletizer 4.5 x FLC
Press 3.5 x FLC
Roller mill 4.5 x FLC
Rotary table 4.0 x FLC
Table 5.8 Typical Start Currents for Transport and Machine
Tool Applications
