Display Possible cause/Suggested solution
Excess start time Excess start time trip can occur under the following conditions:
•
Parameter 1-1 Motor Full Load Current is not appropriate for the motor.
•
Parameter 1-4 Current Limit has been set too low.
•
Parameter 1-6 Start Ramp Time has been set higher than the setting in parameter 1-9 Excess
Start Time Setting.
•
Parameter 1-6 Start Ramp Time is set too short for a high inertia load when using adaptive
control.
Related parameters:
•
Parameter 1-1 Motor FLC.
•
Parameter 1-4 Current Limit.
•
Parameter 1-6 Start Ramp Time.
•
Parameter 1-9 Excess Start Time.
•
Parameter 7-1 Motor FLC-2.
•
Parameter 7-4 Current Limit-2.
•
Parameter 7-6 Start Ramp-2.
•
Parameter 7-9 Excess Strt Time-2.
•
Parameter 16-7 Excess Start Time.
Firing fails px Where X is phase 1, 2, or 3.
The SCR did not re as expected. Check for faulty SCRs and internal wiring faults.
This trip is not adjustable.
Related parameters: None.
FLC too high The soft starter can support higher motor FLC full load current values when connected to the
motor using inside delta conguration rather than in-line connection. If the soft starter is
connected in-line, but the programmed setting for parameter 1-1 Motor Full Load Current exceeds
the in-line maximum, the soft starter trips at start (see chapter 4.5 Minimum and Maximum Current
Settings).
If the soft starter is connected to the motor using inside delta conguration, check that the soft
starter detects the connection correctly. Contact the local Danfoss supplier for advice.
Related parameters:
•
Parameter 1-1 Motor FLC.
•
Parameter 7-1 Motor FLC-2.
Frequency The mains frequency is outside of the specied range.
Check for other equipment in the area that could be aecting the mains supply, particularly
frequency converters and switch mode power supplies (SMPS).
If the soft starter is connected to a generator-set supply, the generator may be too small or could
have a speed control problem.
Related parameters:
•
Parameter 2-8 Frequency Check.
•
Parameter 2-9 Frequency Variation.
•
Parameter 2-10 Frequency Delay.
•
Parameter 16-5 Frequency.
