1Operation
This manual includes basic operation of the
PSV7000 System, but not functions deemed Admin-
istrator functions such as creating a job, teaching
Package Files, or creating a data file from a master
device.
PSV7000 is a programming and handling system for traditional and
fine-pitched integrated circuits (devices). It accepts most all package
types. The on-screen application that run PSV7000 is AH700.
Operator functions include installing some hardware, checking hard-
ware setup, turning on power, starting TaskLink (TL) or LumenX
Data Management Software (DMS), loading a job, and running a job.
Operators generally follow this sequence to process devices:
Figure 1: Operator Functions. For a list of these steps see page 15.
For administrative func-
tions and more, see the
PSV7000 Owner’s Manual
(096-0460...PDF is in
C:\AH700 and also avail-
able on our Technical
Library on our website).
Safety
Precautions
page 8
è
Install media,
check options
page 18
è
Install Socket
Adapters
page 30
è
Check probe
tips / rotor
tips, page 38
è
PSV7000
power up,
page 48
è
Start TL or
LX, load job,
page 49
è
Set UI media
and options
page 54
è
Ensure
Package File
was taught
è
Start Pro-
gramming
page 58
Finishing... è
Finish or stop
a Job
è
Resolving
Basic Errors
