■ Running a Job on PSV7000 ◘ Socket Adapters and Actuator Plates
PSV7000 Operator’s Manual —37—
back
(LumenX) Adjusting the Actuator Plates
To adjust the Actuator Plates (both types, standard and HIC):
Requirements
• Head is parked.
• Actuator for the target programmer is in the UP position (sock-
ets closed).
• The nearest safety door is open.
1. With a 2 mm hex key, loosen both screws for one actuator slid-
ing bar and slide it to align with the socket so that it only con-
tacts the black part of the socket body.
On HIC Adapters, the bars should just cover the socket rollers.
2. Tighten one screw for that bar, recheck alignment and then
tighten the second screw.
3. Perform these steps for the second bar on this Actuator Plate.
4. Test bar placement; with machine air off, manually press the
actuator down to contact the socket body. Ensure it opens the
socket correctly. Readjust the bar if necessary.
Adjust other Actuator Plates similarly as needed.
