AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 29 of 150
Dispensing head
Aux. electronic cabinet
Terminal block
Aux. Refill
Valves
Air Gun
Aux. Refill Air
Regulator
Water refill
valve
Main Air Inlet
Regulator
