Datacolor AutoLab TF Series - Side View of Electronic Cabinet

AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 39 of 150
2-2-5 Side View Of Electronic Cabinet
TF-40/80/120/160
TF-128/168
Leakage circuit breaker
Leakage circuit breaker
RS485
RS485
