AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 7 of 150
CHAPTER1: GETTING TO KNOW YOUR AutoLab TF
1-1 Principle Chart
LA50B
SERVO
module
COMPUTER
PRINTER
LA50B
CPU
module
SERVO
Amplifier
232 to 485
Adapter
BEAKER
SCALE
RS232C
INJECTOR
SERVO
MOTOR
(Z AXIS)
MONITOR
RS232C
RS485
