AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 8 of 150
1-2 Getting To Know AutoLab TF
1-2-1 Standard Specification
AutoLab TF TF 40 TF 80 TF 120 TF 160 TF 88 TF 128 TF 168
Total bottles 40 80 120 160 88 128 168
Number of dye bottles 40 80 120 160 80 120 160
Number of water tank 1 2 2 2 1 1 1
Number of aux. Bottles NONE
7
Number of injectors 40 80 120 160 80 120 120
Number of stirrer 40 80 120 160 87 127 127
Number of agitation 40 80 120 160 87 127 127
Number of agitation area 1 2 3 4 2 3 4
Number of dispense scales 1 2 1
Size of dye bottles 1000㏄
Size of water tank 7 Litre
Size of aux. Bottles incl. Refill NONE 5 Litre
Size of injectors 60㏄
Number of dye pot positions 6 or 4 or 2 or 1
Maximum height of dye pot
（
mm
）
250 250 250 250 350 350 350
Minimum height of dye pot（mm） 60 60 60 60 60 60 60
Readability of dispense scale 0.01g
Accuracy of gravimetric
dis
p
ense
0.02g/+0.3%
Accuracy of volumetric dispense +3%
Dispense speed (12recipes,
3dyes+2chemical+water ）
(dispensing weight of products)
8-10min
Dispense range(kg) 0-4kg
Dimensions Width（mm）
1824 2350 2397 2876 2923 3402 3449
Dimensions Depth（mm）
1423 1423 1725 1423 1725 1423 1725
Dimensions Height（mm）
2007 2007 2007 2007 2007 2007 2007
Weight（kg）
600 800 900 1000 1100 1200 1300
Air pressures required 6.0kg/cm
2
Water pressure required 1kg/cm
2
Diameter of water pipe 1/4”
