Datacolor AutoLab TF Series User Manual

AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 34 of 150
2-1-2 AutoLab TFC 88/128/168
PRINTER
LA50B
CPU
Module
COMPUTER
232 to 485
Adapter
SCALE
LA50B
DIO 0
Module
LA50B
DIO 1
Module
LA50B
DIO 2
Module
LA50B
SERVO
Module
X
AMP
Y
AMP
Z
AMP
RS232C
RS485 RS232C
X
Y
Z
X AXIS SERVO MOTOR
(CONTROL ROBOT X
MOVEMENT
)
Y AXIS SERVO MOTOR
(CONTROL ROBOT X
MOVEMENT
)
Z AXIS SERVO MOTOR
(CONTROL ROBOT X
M
O
VEMENT
)
RESET SENSOR
INPUT
OUTPUT
OUTPUT
INPUT
OUTPUT IDEN
WATER & AUX
LEVEL INPUT
WATER & AUX
REFILL
INPUT IDEN
