AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 38 of 150
2-2-4 Front View Of Electronic Cabinet
DC
POWER
4.5A
LA50B
CPU 0
module
LA50B
SERVO
module
LA50B
D.I.O 0
module
Terminator
LA50B
CPU 1
module
LA50B
D.I.O 1
module
Magnetic contactor
Breaker
Power relay
Fuse connecter
EMI Filter
DS
Relay
Board
Servo Am
p
lifier
